Thickness Indirect Measurement Method for Direct Pulling Pilot Cold Rolling Mill

Abstract:

Pilot cold rolling mill is the important tool for the cold rolling process researching and new steel grade development. According to the design of the new type direct pulling pilot cold rolling mill, based on the mass flow constant principle, strip exit thickness indirect measurement method is studied. During rolling, strip entry and exit speed can be calculated accurately according to the measured value of two sides’ clamps movement. Data filtering treatment is adopted and program flow chart is designed. Based on the material entry thickness measured manually, exit thickness of all passes can be measured indirectly. This thickness indirect measurement method has been applied successfully on the new type pilot cold rolling mill, and the measurement results show that this method has a good accuracy.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 2670-2674
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.2670
• Online since: February 2011
• Authors: Zhi Jie Jiao, Chun Yu He, Jian Ping Li, Xianghua Liu
• Keywords: Mass Flow Constant Principle, Measurement, Pilot Cold Rolling Mill, Thickness

References

[1] Z.J. Jiao, J.P. Li and F.B. Zhang: Iron and Steel Vol. 42 (2007), p.53. In Chinese.

[2] Y.K. Sun in: Computer control of strip tandem cold rolling, Metallurgical industry press，Beijing(2002). In Chinese.
