The Spray Angle Improvement of Single Inlet Pressure Swirl Atomizer Using Partial Structure Modifying

Abstract:

This paper analyzed the velocity field of the section between outlet orifice and the conical swirl chamber with a kind of single inlet pressure atomizer using CFD (Computational Fluid Dynamics) method. A method of modifying the outlet orifice position referring to the swirl chamber in order to improve the spray angle and its homogeneity is proposed. The result of the experiments shows that it is a feasible method to improve the quality of this kind of atomizer.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 189-193)

Pages:

31-37

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.189-193.31

Citation:

Cite this paper

Online since:

February 2011

Authors:

Ji Liang Wu, De Yuan Zhang, Xing Gang Jiang

Keywords:

CFD Simulation, Outlet Orifice Deviation, Single Inlet Pressure Swirl Atomizer, Spray Angle
