Research and Numerical Simulation of Contactor of High-Frequency Welding Device

Abstract:

Based on the production line technology of high-frequency welding H-beam steel, a High-frequency welding device which could be used in a H-beam less than 100mm steel was designed in this work. After virtual prototype established and kinematics Simulation was carried by Solidworks and Cosmos/motion respectively, the trajectory of contact terminal was defined. And the optimal vee angle, high frequency and some other technological parameter were determined through Ansys software, which provides important reference for the design of high-frequency welding H-beam steel.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 3575-3578
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.3575
• Online since: February 2011
• Authors: Da Xing Zhao, Zhi Ming Zhao, Zheng Kun Zhang, Xin Dai
• Keywords: ANSYS, H-Beam Steel, High-Frequency Welding, SolidWorks

References

[1] Huadong Zhu，Chao Lv: Practical Manual of Steel Materials, Standards Press of China, Beijing (2006).

[2] The Welding Institute of Chinese Mechanical Engineering Society, Welding Handbook, Machinery Industry Press, Beijing (2001).

[3] Xiuzi Ye, Chenchao Xiang: Cosmosmotion, Machinery Industry Press, Beijing (2008).

[4] Jianhua Wang, Welding Simulation Technology and Application, Shanghai Jiaotong University Press, Shanghai(2003).

[5] Wang J. et al. Improvement in Numerical Accuracy and Stability of 3-D FEM Analysis in Welding, Welding Journal, 75(4): 129-134(1996).
