Research on Curvature of Tooth Flank of Gleason Spiral Bevel Gears

Abstract:

According to spiral bevel gear machining process, use the method of computer simulation to get the discrete points’ three-dimensional coordinates of Gleason spiral bevel gear tooth surface, and then solve the tooth surfaces’ NURBS surface as the unified mathematical model. On this basis, research the curvature of tooth surfaces of various types of Gleason spiral bevel gear, draw the mean curvature diagram, and study the link between the adjustment of processing parameters and the change of tooth surfaces’ mean curvature. Establish a theoretical foundation for the processing error adjustment based on tooth surface’s curvature diagram.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 4256-4260
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.4256
• Online since: February 2011
• Authors: Ai Mei Zhang, Lin Yan Li, Da Wei Li
• Keywords: Correction of Tooth Flank, Curvature Diagram, Non-Uniform Rational B-Spline (NURBS), Spiral Bevel Gear

References

[1] Zeng tao, Design and Manufacture of Spiral Bevel Gear, Harbin Institute of Technology Publisher（In Chinese 1989）.

[2] F. Di Puccio, M. Gabiccini, M. Guiggiani, Generation and curvature analysis of conjugate surfaces via a new approach , Mechanism and Machine Theory（2006）.

DOI: 10.1016/j.mechmachtheory.2005.07.008

[3] Wang Yanzhong, Ruan Delin, Discrete tooth surface processing method and digital simulation, Machine Tool and Hydraulic Publisher (2007).

[4] Wu Xuntang, Gear engagement theory, Machinery Industry Press (In Chinese 1982).

[5] Zhu Xinxiong, Free Curve and Surface Modeling Technology, Science Press (In Chinese 2001).

[6] Gear Guide Science Press Editorial Board, Gear Guide, Machinery Industry Press (2000).
