Study on Characteristics of Ultrasonic Fields by Hydraulic Model of Ladle Refining

Abstract:

Under ultrasonic irradiation at a frequency of 20 kHz, hydraulic model experiments have been performed to improve the stirring effect in the ladle refining. The cavitation intensity and ultrasonic field distribution were measured by dyeing method. The dynamic behavior of acoustic cavitation bubbles were visualized with a high-speed digital camera. The results show that: the mixing time under ultrasonic can be reduced obviously, and the dynamic conditions can be improved apparently；stable and complete patterns can be got by dyeing method, then relative intensity and the position of antinode and node can be determined from the pattern; the distribution of ultrasonic fields at tool end is circular cone; the cavitation bubbles were confirmed to be generated around the antinode of sound pressure during the ultrasonic stiring and moved linearly in random directions.

• Periodical: Advanced Materials Research (Volumes 194-196)
• Pages: 267-270
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.194-196.267
• Online since: February 2011
• Authors: Shu Mei Kang, Ming Gang Shen, Cheng Wei Li, Hua Chen
• Keywords: Cavitation Bubble, High Speed Camera, Hydraulic Model, Ladle Refining, Mixing Time, Ultrasonic

References

[1] N. Tonanon, W. Intarapanya1, W. Tanthapanichakoon2, H. Nishihara3, S. R. Mukai3 and H. Tamon Journal of Porous Materials. Vol. 15( 2008), p.265.

[2] G. I. Eskin . V. S. Sinyavskii and V. V. Usova. Protection of Metals. Vol. 39(2003), p.551.

[3] Shobhana Vaman Awate1, Suresh Babasaheb Waghmode1, Kashinath Rangu Patil1, Mangala Shripad Agashe1 and Praphulla Narahar Joshi. Korean Journal of Chemical Engineering. Vol. 18(2001), p.257.

[4] Shin-ichi HATANAKA, Tomohito TAKI, Mamoru KUWABARA, Masamochi SANO and Shigeo ASAI. Japanese journal of applied physics. Vol. 38(1999), pp.3096-3100.

[5] Yang Y, Lan J, Li X C. Materials Science and Engineering, Vol. 380 (2004), p.378.
