Optimal Design of Bogie Parameters Determination Test Bench Gantry Framework Based on SolidWorks/Simulation

Abstract:

On the basis of SolidWorks/Simulation FEA module, statics analysis and design optimization for bogie parameters determination test bench gantry framework are researched in this paper. Taking the optimization design of gantry framework main beam for example, an optimal mathematic model is established, the optimization goal is to reduce the quality of the main beam, and the constraints are displacement and stress. Simultaneously, the model is simulated by the SolidWorks/Simulation software. Compared with the initial design, the results show that the quality of main beam is reduced by 12.69%, the quality optimization goal of the gantry framework test bed is realized. Meanwhile, it not only reduced the design and manufacturing cost, but also enhanced the design efficiency.

• Periodical: Advanced Materials Research (Volumes 199-200)
• Pages: 1253-1256
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.199-200.1253
• Online since: February 2011
• Authors: Dong Lin Zhang, Jian Su, Xiao Ning Cao, Hai Bin Gong
• Keywords: Finite Element Analysis (FEA), Gantry Framework, Optimization Design, SolidWorks Simulation

References

[1] X. T. Nie, D. P. Fan: Electomechanical Technology. Vol. 34(2005), p.74(In Chinese).

[2] X. Y. Wang, J. Su, Y. M. Liu, D. M. Zhou: Electric Locomotives & Mass Transit Vehicles. Vol. 32(2009), p.34(In Chinese).

[3] R. mussen John, Lund Erik: Engineering Optimization. Vol. 29(1997), p.23.

[4] Vanderplaats G N: AJAA Journal. Vol. 20(1982), p.992.

[5] J. M. Sun, Y. C. Liang: Optimization of Mechanical Design (China Machine Press, Beijing 2007).

[6] K. S. Wang: Optimal Design of Machine Design (National Defense Industry Press, Beijing 2007).
