Pressure Drop of Y-Shaped Branch Pipe in Gas-Solids Flow

Abstract:

This work concentrated on being able to predict the resistance properties of Y-shaped branch pipe in gas-solid two phase flow. Y-shaped branch pipeline with one branch angle keeping constant and the other being changeable experimental system was built up. Micro-glass bead and millet with similar particle diameter and different solid density were conveyed in the experimental system. As a result, trends of pressure drop on each branch pipe were expressed to perform resistance properties. It can be concluded that pressure drop of the two materials had similar trend and was significantly affected by the branch angle and gas velocity. Meanwhile, the deposition velocity was defined in this study. The relationship between the solids loading ratio and pressure drop on each branch pipe was given based on experimental data, which agreed the theoretical analysis well.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 2246-2249
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.2246
• Online since: February 2011
• Authors: Zong Ming Liu, Guang Bin Duan, Guang Li Chen
• Keywords: Gas-Solid Two Phase Flow, Pressure Drop, Resistance Property, Y-Shaped Branch Pipe

References

[1] Nestor Vasquez, Karl Jacob and Ray Cocco: Powder Technology Vol. 179 (2008), p.170–175.

[2] Yan Y: Powder Handling and Processing Vol. 141 (2002), pp.12-21.

[3] Muslihin Hidayat and Anders Rasmson: Powder Technology Vol. 153 (2005), pp.1-12.

[4] Akira Rinoshika: Powder Technology Vol. 198 (2010), pp.49-55.

[5] Wenhao Pu and ChangsuiZhao: Chemical Engineering Science Vol. 16 (2010), pp.1-9.
