Symmetric Beauty: Double-Position Numerical Control Press Based on Lever-Toggle Force Amplifying Mechanism Driven by Linear Servo Motor

Abstract:

According to the conception of symmetric beauty in the aesthetics, a new kind of numerical control press with double operating positions based on lever-toggle force amplifying mechanism driven by linear servo motor is introduced here. Its working principle, characteristic features and mechanical calculating formulas are given also. Compared with traditional mechanical press based on the crank-linkage-slider mechanism driven by common AC motor, the system has following advantages: two operating positions, higher energy transmission and production efficiency, no environmental pollution; lower cost of machine tool. Through rationally designing the acceleration curve of the pressure head, the impacting noise of the system can be reduced greatly. This press is especially suitable for blanking and low-stretching process.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 2250-2253
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.2250
• Online since: February 2011
• Authors: Fan Wu, Ming Di Wang, Kang Min Zhong
• Keywords: Force Amplifying Mechanism, Lever, Linear Servo Motor, NC Press, Symmetric Beauty, Toggle

References

[1] Symmetry Aesthetic and Creative Machine Design. Zhong Kangmin, Wang Mingdi. CHINESE Journal of Soochow University Engineering Science Edition (Bimonthly), 2004, 24(5)：pp.36-37.

[2] Zhong Kangmin, Dou Yunxia, Su Dongning, Wang Hongyan. CNC Press Based on the High-Speed Linear Servo Motor and Two-stage Symmetrical Orthogonal Toggle Force Amplifying Mechanism. Proceedings of ASME 2009 International Mechanical Engineering Congress and Exposition.

DOI: 10.1115/imece2009-11019

[3] Chen. Z.S., 2009, The Innovative Design and the Research of Force-amplifying Type Crank Press Based on Symmetrical Layout, Soochow University, MA Dissertation.

[4] CHEN Zhi-song, ZHONG Kang-min Analysis and application of hinge-rod and lever series connected combination mechanism. Journal of Machine Design2010(1)：P. 57-58.

[5] Lu, W., Wang, B. and Zhong, K.M., 2005, Three kinds of composition system for pneumatic muscle and force amplification mechanism of hinge rod and their comparisons, Journal of Machine Design, Vol. 22(2), pp.52-54.

[6] Ye, Y.F., 2000, The Principle and application of Linear Motor, 2000．China Mechanical Industry Press, Beijing.

[7] Ye, Y.Y., 2002, New Type Linear driving Device and System, Metallurgical Industry Pres, Beijing.

[8] Xu, D.R., 2005, AC Servo Press and Its Application, Machinist Mental Forming, Vol. 4, pp.19-21.
