Experimental Study on the Plastic Collapse Load of Elbows Subjected to In-Plane Opening Bending Moment

Abstract:

Pipe elbows are the most critical components in any piping system. However, the earlier experiments on cracked elbows were focused mainly on the determination of limit load of through wall cracked elbow. The experimental results of plastic collapse load of seven carbon steel 90⁰ elbows, subjected to in-plane opening bending moment, are reported in this work. Among the selected specimens, three were defect-free elbows and six had axial surface cracks at the intrados, crown or at extrados. Test arrangement and the collapse behavior with and without cracks were presented. The plastic collapse loads were then obtained on the basis of experimental results. Reasonably good matching between test results and existing estimation formulae has been observed.

• Periodical: Advanced Materials Research (Volumes 204-210)
• Pages: 1755-1758
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.204-210.1755
• Online since: February 2011
• Authors: Cha Xiu Guo, Xin Li Wei
• Keywords: Bending Moment, Crack, Elbow, Experimental Study, Plastic Collapse Load

References

[1] Gloucester: R6, UK, Nuclear Electric Ltd. ( 2000).

[2] AG Miller: Int J Pressure Vessels Piping Vol. 32(1988), p.197–327.

[3] ASME. Boiler and pressure vessel code, section III, subsection NB. New York (1996).

[4] C.X. Guo: Ph. D Thesis, East China University of Science and Technology, Shanghai, China (2000).
