Realization of Three-Dimensional Nanostructure Fabrication by Nanoimprint on Silicon Substrate

Abstract:

Traditional optical lithography techniques to fabricate three-dimensional (3D) nanostructures are complicated and time consuming. Due to the capability to replicate nanostructures repeatedly in a large area with high resolution and uniformity, nanoimprint (NI) has been recognized as one of the promising approaches to fabricate 3-D nanostructures with high throughput and low cost. This paper introduces a novel 3-D nanostructure fabrication method by nanoimprint on silicon substrate. Nanoscale gratings and microlens array are taken as examples of 3-D nanostructures fabricated by nanoimprint. High fidelity demonstrates the possibility of nanoimprint to fabricate 3-D nanostructures on silicon substrate.

• Periodical: Advanced Materials Research (Volumes 211-212)
• Pages: 1105-1109
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.211-212.1105
• Online since: February 2011
• Authors: Xi Qiu Fan
• Keywords: Nanoimprint, Nanostructure, Three-Dimension
