Based on Pro/E Construction Method of Spiral Bevel Gear Logarithm

Abstract:

For a new type of bevel gear named as logarithmic spiral bevel gear, establish its tooth direction curves and the mathematical model of tooth surface equation. With CAD software platform which can intuitive understanding of complex curves and combined with conical logarithmic spiral parameter equation build the logarithmic spiral on cone surface. Then array logarithmic spiral to make them evenly distributed in the cone surface, without any interference and to meet the strength distribution on both ends of circular truncated cone equally. Use two logarithmic spirals from different starpoint as tooth direction curves of lift and right tooth surface. Finally, use space geometric knowledge to build tooth surface equation by tooth direction curves and tooth profile curves.
