The Dynamics Analysis of Rolling Movable Teeth Reducer

Abstract:

The structure and operating principle of rolling movable teeth reducer are introduced in this paper. Through the virtual prototype technology, the modeling of rolling movable teeth reducer is made by Pro/E software,and is had the kinematics simulation and dynamic analysis by ADAMS software. The simulation results show that the speed curves of the input shaft and the output shaft of rolling movable teeth reducer coincide with the theory transmission. It proves correctness of virtual prototype. The mechanical properties of rolling movable teeth reducer is obtained by the time-domain graph of meshing force. It provides the basis for the optimization design and engineering analysis of reducer.

• Periodical: Advanced Materials Research (Volume 221)
• Pages: 429-435
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.221.429
• Online since: March 2011
• Authors: Jun Fei Wu, Xiao Chen Zhu, Wei Gao, Ying Yu
• Keywords: Adam, Dynamic, Kinematics, Rolling Movable Teeth Reducer, Simulation

References

[1] QU Ji-fang. Theory of oscillator drives[M]. Beijing: Mechanic industry Press, (1993).

[2] XU Xiu-hua, SUN Jia-lin, JIANG Hong-kui. The solution and analysis of the tooth profile equations of central gear of movable teeth reducer[J]. MACHINE DESIGN AND RESEARCH, 2004, 20(6): 41-43.

[3] CHEN Li-ping, ZHANG Yun-qing, REN Wei-qun and so on. Kinetic analysis of mechanical system and the application guide of ADAMS[ M]. Beijing: Tsinghua University Press, (2005).

[4] LI Gui-xian, YANG Wei-jun. Study of the stress distribution of rolling movable teeth reducer [J]. MACHINE DESIGN AND RESEARCH, 2001(4).

[5] LI Zeng-gang, The induction and example of ADAMS [M]. Beijing: National Defence Industrial Press, (2006).
