Autocontrol of Water Condenser Based on PID Controller

Abstract:

To maintain the outlet temperature at the desired set-point, a high-order outlet temperature control model is established for a water condenser, and different PID controller design methods are applied to its temperature control process. The control function model is based on the analysis of the heat balance equation and the heat transfer rate equation. The design process of three different PID control methods, including Ziegler-Nichols Method, Modified Ziegler–Nichols Formula and the Optimum PID Controller, together with the unit step response consequence are provided and compared, and the numerical simulation results show that the Optimum PID Controller has a favorable control performance.

• Periodical: Advanced Materials Research (Volumes 225-226)
• Pages: 186-189
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.225-226.186
• Online since: April 2011
• Authors: Xing Hua Yang, Ting Rui Liu, Ai Qin Sun
• Keywords: Condenser, Modified Ziegler–Nichols Formula, Optimum PID Controller

References

[1] A. Abbassi, L. Bahar . Application of neural network for the modeling and control of evaporative condenser cooling load. Applied Thermal Engineering. Vol. 25 (2005), p.3176.

DOI: 10.1016/j.applthermaleng.2005.04.006

[2] A. Maidi, M. Diaf, J. Corriou. Optimal linear PI fuzzy controller design of a heat exchanger. Chemical Engineering and Processing. Vol. 47(2008), p.938.

DOI: 10.1016/j.cep.2007.03.008

[3] D. Xue: Computer aided control systems design using MATLAB language (in Chinese). Tsinghua University Press, China, Beijing( 2006) , p.210.

[4] D. Xue, Y. Chen: Matlab solutions to mathematical problems in control(in Chinese). Tsinghua University Publishing Company, China, Beijing(2007), p.372.
