Numerical Calculation and Analysis of Mechanical Strength of Steel Wire Product

Abstract:

To obtain the influence law of laying combination and lay pitch multiple on mechanical strength of steel wire product, we took 6×19IWS right lang lay and right regular lay wire ropes as examples, combining with the strength theory, nonlinear finite element analysis were carried out with ANSYS software. The simulation results show the mechanical strength of the lang lay wire rope is better than that of the regular lay at the same lay pitch multiple; the lay pitch multiple of rope has a great impact on mechanical strength of steel wire product, however, the impact trend is similar among difference laying combinations, meanwhile the effect of the lay pitch multiple of strand is relatively small. Finally, finite element model for wire rope was verified reasonable through tensile experiment. Research results have important applications value for structural design and rational use of wire rope.

• Periodical: Advanced Materials Research (Volumes 228-229)
• Pages: 1022-1028
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.228-229.1022
• Online since: April 2011
• Authors: Dao Ming Wang, You Fu Hou, Qing Rui Meng
• Keywords: Finite Element Model (FEM), Mechanical Strength, Numerical Calculation, Steel Wire Product

References

[1] G.L. Wang, H.O. Zhang: Journal of Huazhong University of Science and Technology, Vol. 29 (2001), p.65.

[2] J. Ma, S.R. Ge and D.K. Zhang: Journal of Mechanical Engineering, Vol. 45 (2009), p.277.

[3] W.G. Jiang, J.L. Henshall and J.M. Walton: International Journal of Mechanical Sciences, Vol. 42 (2000), p.63.

[4] J.F. Sun, G.L. Wang and H.O. Zhang: Journal of System Simulation, Vol. 17 (2005), p.1746.

[5] S.W. Wang, J.L. Feng, Z.J. Yang and F. L Chen: Advances in Mechanics, Vol. 29 (1999), p.486.

[6] R.E. Hobbs, M. Raoof: Behavior of Offshore Structures, Vol. 2 (1982), p.77.

[7] G.A. Costello: Theory of Wire Rope (Spring, Berlin 1990), p.58.

[8] J.F. Sun: Numerical Simulation on Laying Process and Strength Analysis of Metal Wire Rope (Ph.D., Huazhong University of Science and Technology, China 2004), p.75.

[9] Z.J. Ni: Research on Mechanics Capability and Failure Mechanism of Wire Rope (MS., Kunming University of Science and Technology, China 2008), p.31.

[10] W.G. Jiang, M.S. Yao and J.M. Walton: International Journal of Mechanical Sciences, Vol. 41 (1999), p.143.

[11] J. Ma, S.R. Ge, D.K. Zhang: Journal of Mechanical Engineering, Vol. 45 (2009), p.259.

[12] J. Ma, S.R. Ge, D.K. Zhang: Journal of China University of Mining and Technology, Vol. 18 (2008), p.475.
