Influence of Media Loss on Semi-Passive Piezoelectric Sound Insulation

Abstract:

Piezoelectric material shunted with negative capacitance can be used to insulate sound theoretically. But sound insulation of the system is limited by many factors. The dielectric and mechanical loss of the piezoelectric system deteriorate seriously the ability at some frequencies. According to the ideal electric elements formulas, the capacitance has imaginary part because of the loss. It has important influence on sound insulation ability. If a series resistance is introduced into the shunting circuit to form the imaginary part to compensate the loss, it is dependent on frequency. Sound insulation would be increased only in narrow band, and at some frequencies the system with the shunting circuit even becomes unstable.

• Periodical: Advanced Materials Research (Volumes 230-232)
• Pages: 1181-1184
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.230-232.1181
• Online since: May 2011
• Authors: Wen Qun Zhang, Xin Yue Wu, Wen Cao
• Keywords: Media Loss, Negative Impedance, Piezoelectric, Sound Insulation

References

[1] M. Date, M. Kutani and S. Sakai: Electrically controlled elasticity utilizing piezoelectric coupling, J. Appl. Physics, Vol. 87(2000), p.863.

DOI: 10.1063/1.371954

[2] P. Mokry, E. Fukada and K. Yamamoto: Attenuation of the sound transmitted through the piezoelectric curved membrane: the effect of the electrically controlled elasticity, IEEE 11th international symposium on electrets(2002), p.227.

DOI: 10.1109/ise.2002.1042985

[3] E. Fukada, M. Date and K. Kimura: Sound isolation by piezoelectric polymer films connected to negative capacitance circuits, IEEE Transactions on Dielectrics and Electrical Insulation(2004), Vol. 11, no. 2, p.328.

DOI: 10.1109/tdei.2004.1285904

[4] E. Fukada, M. Date and H. Kodama, etc: Elasticity control of curved piezoelectric polymer films, Ferroelectrics, Vol. 320(2005), p.3.

DOI: 10.1080/00150190590966720

[5] W. Q. Zhang, M. Zhang and X. Y. Wu: Energy Dissipation Performance of A Piezoelectric Shunted System with Negative Capacitance, Journal of vibration and shock, Vol. 27 no. 10(2008), p.70, in Chinese.

[6] Y. J. Kim: Broadband Noise Reduction of Piezoelectric Smart Panel Featuring Negative Capacitive Converter Shunt Circuit, J. Acoust. Soc. Am., Vol. 120, no. 4(2006), p. (2017).

DOI: 10.1121/1.2259791

[7] S. Y. Wu: Broadband Piezoelectric Shunts for Passive Structural Vibration Control, Proc of SPIE, Vol. 4331(2001), p.251.

[8] W. Q. Zhang, X. Y. Wu and W. Cao: Research on Semi-Passive Shunted Piezoelectric Membrane for Sound Isolation with FEM, doi: 10. 4028/ www. scientific. net/AMM. 34-35(2010). 1248.

DOI: 10.4028/www.scientific.net/amm.34-35.1248
