FEM Research on Static Mechanical Performance of Twice Prestressed Composite Curved Beam

Abstract:

The conception of twice prestressed composite structures (TPCS) was proposed in order to solve great distortion problems in prestressed concrete structures. Through decomposition of the total prestress, we define the 1st stage as one part of the prestress acting on a prefabricated beam, and the 2nd as the other part on a post-pouring structure. This kind of structure could substantially decrease its distortion and enhance the efficiency of prestress, at the same time contributing to flexibly laying the prefabricated concrete. A continuous curved prestressed concrete box girder bridge was modeled with the FEM software ANSYS, taking into account the ordinary steel and prestressed losses. The aim is to analyze the deformation, stress performance, the impacts of the primary prestressed force value on the anti-deforming performance as well as bearing load performance of the twice prestressed composite curved beam. The conclusion could provide a basis for the application and promotion of the structure.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 1038-1042
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.1038
• Online since: May 2011
• Authors: Fang Fang Wei, Jin Bo Wang, Ben Wei Zou, Hao Sun
• Keywords: Curved Beam, Finite Element Model (FEM), Static Mechanical Performance, Twice Prestressed Composite

References

[1] Xudong Shao, Haibo Liu and Lifeng Li. (2003). "Explorative research on double prestress technique applied to bridge structure." J. Highway, Vol. 36 (2): 93-96.in Chinese.

[2] Xudong Shao, Cong Peng and Lifeng Li. (2006). "Analysis of twice prestressed continuous beam in construction stage." J. Central South Highway Engineering, Vol. 31 (2): 73-76. in Chinese.

[3] Wei Zhang. (2004). "Study on ultra thin beam of double prestressed composite structure and its experiment." Chang Sha: Hunan University. in Chinese.

[4] Xianchao Li. (2007). "Study on bearing capacity of twice prestressed composite structure continuous beam." Chang Sha: Hunan University. in Chinese.

[5] Meichun Nie. (2009). "Study on application of ballstless track twice prestressed concrete composite beam." Chang Sha: Hunan University. in Chinese.

[6] Jun Qu. (2008). "Model test and bearing capacity study of curved prestressed concrete box girder bridge." Chang Sha: Hunan University. in Chinese.

[7] Xinmin Wang. "ANSYS numerical analysis of engineering structures." China Communication press, 2007. in Chinese.
