Numerical Simulation of Vibration of Highway Cable-Stayed Bridge with Steel Arch Tower due to Moving Vehicle Loads

Abstract:

Recently, with the development of highway traffic cause and long-span bridges, the vibration performances of highway bridges due to moving vehicle loads have attracted more and more attention. The vibration of a cable-stayed bridge with steel arch tower subjected to vehicle loads was studied in this paper. Firstly, the dynamic model of vehicle and finite element model of bridge were built and the dynamic differential equations of vehicle model and vehicle-bridge coupled system were derived. Then road roughness was simulated using superposition method of trigonometric series. Finally, the bridge responses caused by vehicle loads were calculated numerically. Furthermore, the effects of road roughness, vehicle velocity and bridge damping on bridge responses and their dynamic amplification factors were studied. The results and conclusions of present study are expected to be useful for the future revision of bridge design codes and maintenance and management of bridge.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 1614-1620
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.1614
• Online since: May 2011
• Authors: Xin Li, Li Liang, Fu Chun Wang
• Keywords: Cable-Stayed Bridge, Dynamic Amplification Factor, Numerical Method, Parametric Analysis, Vibration due to Vehicle Loads

References

[1] X. Z. Li, L. M. Zhang and J. Zhang: Eng. Mech. Vol. 25 (2008), p.230. (In Chinese)

[2] G. H. Li: Stability and Vibration of Bridge Structures (China Railway Publishing House, Beijing 2002). (In Chinese)

[3] S. H. Ju and H. T. Lin: J. Sound Vib. Vol. 303 (2007), p.46.

[4] Y. F. Song: Dynamic of Highway Bridges (China Communication Press, Beijing 2002). (In Chinese)

[5] L. X. Wang and H. Y. Wang: Vehicle Dynamics (National Defense Industry Press, Beijing 2008). (In Chinese)

[6] X. Li, L. Liang and K. L. Chen, in: 2010 International Conference on Mechanic Automation and Control Engineering (2010), p.4566.

[7] P. Z. Lin and S. Z. Liu: Finite Element Analysis of Bridge Structures (Science Press, Beijing 2008). (In Chinese)

[8] L. Deng and C. S. Cai: Eng. Struct. Vol. 32 (2010), p.21.

[9] ISO 8608: Mechanical vibration-Road surface profiles-reporting of measured data (1995).

[10] R. Clough and J. Penzien: Dynamics of Structures (McGraw-Hill, New York 1993).

[11] CCCC Highway Consultants: General code for design of highway bridges and culverts (China Communication Press, Beijing 2004).

[12] Y. Zhang, C. S. Cai, X. M. Shi and C. Wang: J. Bridge Eng. Vol. 11 (2006), p.410.
