Geometric Nonlinear Analysis of Curved Box Continuous Girders Considering Shear Lag Effect

Abstract:

The analytical theory and computational method for thin-walled curved box girders in terms of the shear lag effect and geometric nonlinearity are presented. Based on the potential variational principle and the theory of thin-walled box girders, the geometry nonlinear governing differential equations of thin-walled curved box girder considering the influence of the shear lag effect of flange’s stress and the large deflection is established. The equation is solved by means of Newton-Raphon iteration method. The results from the present method are in good agreement with those of the test and the segment method. The numerical examples are conducted to verify the accuracy and reliability of the present theories. It is shown that the proposed formulae and method could be referenced to the design for the thin-walled curved box girders considering shear lag effect.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 1811-1816
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.1811
• Online since: May 2011
• Authors: Qi Zhi Luo, Yu Ji Chen
• Keywords: Curved Box-Girder, Geometric Nonlinearity, Shear Lag, Spline Function

References

[1] Malcolm D.J., Redwood R.G: J.Struct. Div.,ASCE, Vol.96 (1970), pp.1403-1419.

[2] Van Dalen K., Narasimham S.V: J.Struct.Div., ASCE, Vol.102(1976) , pp.1969-1979.

[3] Kuzmanovic B.O., Graham H.J. Shear lag in box girder. J.Struct.Div., ASCE, Vol.107(1981) , pp.1701-1712.

[4] Evans H. R., Ahmad M.K.H., Kristek V. Shear lag in composite box girders of complex cross-section. J. Construct.Steel Res., Vol.24(1993) , pp.183-204.

DOI: 10.1016/0143-974x(93)90043-r

[5] Luo Q.Z., Tang J., Li Q.S. Negative shear lag effect in box girders with varying depth. J. Struct. Engrg., ASCE, Vol.127(2001) , pp.1236-1239.

DOI: 10.1061/(asce)0733-9445(2001)127:10(1236)

[6] Luo Q.Z., Li Q.S., Tang J. Shear lag effect in box girder bridges. J. Bridge Engrg., ASCE, Vol.7(2002) , pp.308-313.

DOI: 10.1061/(asce)1084-0702(2002)7:5(308)

[7] Luo Q.Z., Tang J., Li Q.S. Finite segment method for shear lag analysis of cable-stayed bridges. J. Struct. Engrg., ASCE, Vol.128(2002) , pp.1617-1622.

DOI: 10.1061/(asce)0733-9445(2002)128:12(1617)

[8] Luo Q.Z., Tang J., Li Q.S., Liu G.D.,Wu J.R. Membrane forces acting on thin-walled box girders considering shear lag effect. Thin-walled Structures, Vol.42(2004) , pp.741-757.

DOI: 10.1016/j.tws.2003.12.009

[9] Yang Y.B., Kuo S.R., Cherng Y.P. Curved beam element for nonlinear analysis. J.Engrg.Mech.,ASCE, Vol.115(1989) , pp.840-855.

DOI: 10.1061/(asce)0733-9399(1989)115:4(840)

[10] Yeong J.K. Chaj H.Y. Thin-walled curved beams I: Formulation of nonlinear equation. J.Engrg.Mech.,ASCE, Vol.120(1994) , pp.2072-2101.

[11] Luo Q.Z., Li Q.S. Shear lag of thin-walled curved box girder bridges. J.Engrg.Mech.,ASCE, Vol.126(2000) , pp.111-114.

DOI: 10.1061/(asce)0733-9399(2000)126:10(1111)

[12] Du J.B: The shear lag analysis for continuous curved box girders and its test research. Master degree thesis, South China University of Technology, 2005(In Chinese).
