Study of “Wave Type” Uneven Settlement and Reinforcing Method of Soft Clay Foundation

Abstract:

The deformation is the dominant factor of the quality of the road constructed on the soft soil foundation. Tianjin DongJiang port is located on the hydraulic filled soil foundation which is improved by using vacuum preloading method. Roads in this area often suffer wave type asymmetry settlement, which serious affects the usage of the road and causes damage to both vehicles and human being. It is found that the initial wave asymmetry deformation of the road on very soft soil foundation usually exists and will be developing continuously under the traffic load. The mechanism of the wavy failure of the road is discussed by establishing a mechanical model. The method of using geogrids to reduce the asymmetry deformation is proposed, the reinforce effect is analyzed using finite element method.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 2990-2996
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.2990
• Online since: May 2011
• Authors: Li Qiang Sun, Shu Wang Yan, Hong Juan He, Yu Xu
• Keywords: Asymmetry Settlement, Geogrids, Soft Subsoil Foundation, Soil Improvement, Wave Type Deformation

References

[1] Ye Yang, Song-yu Liu, Yong-feng Deng, Effect of reinforced subgrade on differential settlement by model test research[J], Rock and Soil Mechanics, 2009,(03):703—711.(in Chinese)

[2] Ming-hua Zhao, Jian-hua Liu, Liu Yu, Huan-ran Zheng, Deformation Mechanism and Settlement Forecast of soft clay embankment[J], Journal of Highway and Transportation Research and Development, 2006,(01):32-35. (in Chinese)

DOI: 10.1061/jhtrcq.0000140

[3] Yun-feng Li, Rui-ning Hu,The formation and countermeasures to subgrade uneven sedimentation[J], Journal of ChongQing JiaoTong University, 2006,(06):85-88. (in Chinese)

[4] Jia-fan Zhang, Hui-mei Zhang, Additional stress in pavement structure due to asymmetrical settlement of soft subgrade, Journal of Chang'an University(Natural Science Edition,) 2003, (05): 21-25. (in Chinese)

[5] Ming-hua Zhao, Yu Liu, Wen-gui Cao, The developing regularity and forecasting of settlement in soft clay roadbed,J.CENT.South UNIV.(Natural Science), 2004,(2):157-161. (in Chinese)

[6] Wei-lu Chen, Settlement calculation of urban road above weak subgrade,An'Hui Architecture, 2008(05):155-157. (in Chinese)

[7] Xian-chao Xiang, Ren Wang, Chang-qi Zhu, Analysis of soft foundation instant settlement in seaside areas, Rock and Soil Mechanics, 2005(07): 1095-1098. (in Chinese)

[8] Jian-ming Ling, Wei Wang, Hong-bo Wu, On residual deformation of saturated clay subgrade under Vehicle load, Journal Of TONGJI University, 2002(11)：1315-1320. (in Chinese)

[9] Da-xin Geng, You-gen Zhong, Ming-xin Zheng, Research on Similarity Relationship for model-based creep Experiment of prestressed concrete bridges Journal Of East China Jiaotong University, 2007(04):47-51. (in Chinese)
