Experimental Study of Damage Variable Law of Bridge and Tunnel with Underlying Goaf during Expressway

Abstract:

This paper takes geological conditions of the Li—Jun expressway by Kang JiaGou and Tong De coal mine goaf as prototype, using the simulation experiment of similar material, simulates the formation process and distribution of the mined rock fracture and the damage variable of the mined rock by using the simulation experiment of similar material, At the same time, It researches the evolvement law of rock’s fracture network in caving zone, fractured zone over goaf using fractal geometry theory. It analyses the damage variable law in caving zone, fractured zone using the damage mechanical theory, and found the relationship of damage variable and mined width. The conclusion of the experiment indicates: with the advance of the working surface, the fractal dimension of the mined rock crack goes through small → large →small, and stable process of change. In the identical push distance of the working surface, fractal dimension of caving zone is 1.0—1.2 times of fractured zone. With the advance of the working surface, damage variable increases gradually, under the identical mined width, damage variable of caving zone is greater than fracture zone, caving zone is about 1.04—1.11 times of fracture zone. Damage variable of goaf central zone is greater than edge.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 3062-3066
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.3062
• Online since: May 2011
• Authors: Xiu Ying Liu, Guo Ping Di
• Keywords: Damage Variable, Expressway, Fractal Dimension, GOAF

References

[1] G.X. Cui: Similarity Theory and Model Experiment(China university of mining and technology press, Chinese1990)

[2] W.G. Cao M.H. Zhao,and X.J. Tang: Chinese Journal of Geotechnical Engineering. Vol.25(2) (2003), p.184 (in Chinese)

[3] X.Y. Liu and Y.B. Zhang: Journal of Taiyuan university of technology. Vol.35(1) (2004), p.29. (In Chineses)

[4] Y.B. Zhang and X.Y. Liu: Ground pressure and strata control. Vol.21(2) (2004), p.94 (In Chinese)

[5] L.Cheng and Y.B. Zhang: Experimental Study of Analog Simulation on Stability Analysis of Bridge and Tunnel with Underlying Goaf during Expressway (Taiyuan university of technology Chinese 2008)

[6] G.L. Guo, G.Q.He and Z.C. Qiao: Mining Science and Technology, A. A. Balkem a/Rotterdam/Brookfield (1996)

[7] X.L. Yao, D.J. Reddish and B.N. Whittaker. Nonlinear Finite Element Analysis of Surface Subsidence Using From Inclined Seam Extraction, Int. J. RODK , Mech. & Mining SCI.(1993)

DOI: 10.1016/0148-9062(93)91724-w
