Nonlinear Stability Analysis on Vessels Subjected to External Pressure

Abstract:

To determine stability performance and the critical load of the short cylinder vessel which is made of steel, this paper carried out the finite element linear buckling analysis for 5 meters long steel pressure vessel and obtained buckling critical load. Then performed the nonlinear instability analysis by the arc-length method and obtained the load-displacement curves of the overall stability of the pressure vessel structure. The critical load can be got by twice the elastic slope method and double-tangent intersection method, and the loads are slightly higher than the result of the theoretical calculation, so the result of the theoretical calculation is safe and reliable. Finally, several measures keeping stability of short cylinder pressure vessel are proposed.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 5214-5218
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.5214
• Online since: May 2011
• Authors: Zhen Chao Teng, Jing Ji
• Keywords: Arc-Length Method, Geometric Nonlinear Analysis, Overall Stability, Vessels Subjected to External Pressure

References

[1] Schindler S and Zeman J L: International Journal of Pressure Vessels and Piping.Vol.80 (2003), p.87

[2] ShaoFeng Zang and Caifu Qian: Journal of Beijing University of Chemical Technology (Natural Science). Vol. 36(2009), p.88(in Chinese)

[3] Guodong Ren, Chunyuan Kong and Xiuling Ren: Mechanical Engineering & Automation. Vol. 11 (2010), p.68 (in Chinese)

[4] Xiaodong Xu, Yan Liu and Weiqiang Wang: Journal of Shandong University (engineering science).Vol.39 (2009), p.101 (in Chinese)

[5] Wenhua Hao: ANSYS application case in civil engineering (Waterpower Press, China 2005)

[6] Jingbo Liu and Xiuli Du: Dynamics of Structure (Mechanical industry press, China 2005)

[7] Boming Ding: American pressure vessel normative analysis ASME VIII-1 and VIII-2 (East China university of science and technology press, China 1995)
