Numerical Simulating Method of the Deflection of Cellular Voided Slabs Fixed Supported by Four Edges

Abstract:

Based on the construct detail, structural behavior of cellular voided slab was analyzed. Differential equilibrium equations and formulae of flexural and torsional stiffness of the cellular voided slabs were given. Solution of deflection of cellular voided slabs fixed supported by four edges were presented by numerical simulating method. Analysis and comparison by elastic finite element method on three group ensamples were carried out. The errors in numerical solutions to finite element method analysis results are little; the solution of deflection was applicable to solve cellular voided slabs fixed supported by four edges.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 6030-6035
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.6030
• Online since: May 2011
• Authors: Yuan Bing Cheng, Hong Wei Du, Xiao Yan Yang, Chao Yang
• Keywords: Cellular Voided Slab, Deflection, Finite Element Model (FEM), Numerical Simulating Method, Weighted Residual Method

References

[1] Cheng Wenrang, Jiang Han, Gao Zhongxue, et al. Experimental study of tubular voided flat plate floor[J], Journal of Building Structure, 2004, 25(5): 78-84. (in Chinese).

[2] Elliot G, Clark L A. Circular voided slab stiffness[J], Journal of the Structure Division, ASCE, 1982, 108(ST11): 2379-2393.

[3] Gao Zhongxue, Cheng Wenrang, Chen Dewen, et al. The design and construction of the multi-cell flat plate floor using thin wall boxes[J], Special Structures, 2002, 19(2): 45-48. (in Chinese).

[4] Cheng Wenrang, Wang Jianfei, Wu Qiang, et al. Design and research for the cellular voided two way RC slab with long span[J], Building Structure, 2004, 34(10): 46-48. (in Chinese).

[5] Han Jinsheng, Cheng Wenrang, Hu Hemin, et al. Design and research of cellular voided flat plate floor in underground garage [J], Special Structures, 2005, 34(2): 47-50. (in Chinese).

[6] Hashim M S，KhalilA M H. Rigidity and strength of orthotropic reinforced concrete waffle slabs[J], Journal of structural engineering, 2000, 126(2): 219-227.

DOI: 10.1061/(asce)0733-9445(2000)126:2(219)

[7] Kennedy J B, Iyengar K J. Rigidities of nonorthogonally shaped waffle slabs[J], Journal of the Structure Division, ASCE, 1982, 108(10): 2263-2272.

DOI: 10.1061/jsdeag.0006055

[8] Andrzej B A, Alina T K. Experimental analysis of limit states in a six-panel waffle flat-plate structures[J], ACI Journal, 1986, 83(6): 909-915.

DOI: 10.14359/2633

[9] Takabatake H, Yanagisawa N. A simplified analysis of rectangular cellular plates[J], Int. J. Solids Structrures, 1996, 33(14): 2055-(2074).

DOI: 10.1016/0020-7683(95)00145-x

[10] Cheng Yuanbing, Zhao Quanru, Dang Ji, et al. Analytical solution of cellular voided plates simply supported by four edges subjected to uniformly distributed loads[C], 12th International conference on inspection, appraisal repairs and maintenance of structures, 2010, Vol. (1): 261-268.

[11] Edit group of Static calculation menu of building structures. Static Calculation Menu of Building Structures[M], China construction press, Beijing, (1975).
