Calculation of Unlimited Passive Earth Pressure in the Model of RBT Movement

Abstract:

Assuming the internal friction angle of backfill and the displacement are in nonlinear, to adopt the calculation model that was put forward by the author, combined with the in-room model experiment, to calculate and analyze the passive earth pressure acted on the retaining wall in the model of RBT movement. The analysis results show: the calculated values and the test values can agree with each other very well in the three ways of the distribution of earth pressure along the wall height, the values of the passive total force and its action point position. So it is feasible to use the calculation model to calculate the passive earth pressure in the model of RBT movement. Comparatively, when n = 0 the calculated values are the most identical with the test values, when n = 0.25 are worse, when n = 0.5 are the worst. Those may be relative to the sizes effect of the box of model test and the property of the interface between the soil and the plate at the bottom of model box. In addition, with the value of n increasing gradually, the maximum displacement needed to reach Rankine’s passive limit state will be decreased.

• Periodical: Advanced Materials Research (Volumes 250-253)
• Pages: 1572-1577
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.250-253.1572
• Online since: May 2011
• Authors: Tai Hua Yang, Huai Jian He
• Keywords: Earth Pressure, Movement Model, RBT, Unlimited State

References

[1] BANG S. Active earth pressure behind retaining walls [J ] .Journal of Geotechnical Engineering,1985 ,111 (3) : 407-412.

DOI: 10.1061/(asce)0733-9410(1985)111:3(407)

[2] FANG Y S , ISHIBASHI I. Static earth pressure with various wall movements [ J ] . Journal of Geotechnical Engi-neering ,1986 ,112 (3) : 317-333.

DOI: 10.1061/(asce)0733-9410(1986)112:3(317)

[3] XU Ri-qing , CHEN Ye-kai , YANG Zhong-xuan , et al .Experimental research on the passive earth pressure acting on a rigid wall [J ] . Chinese Journal of Geotechnical Engineering ,2002 , 24 (5) : 569-575.

[4] ICHIHARA M ,MATSUZAWA H. Earth pressure during earthquake [J ] . Soils and Foundations, 1973 ,13 (40) : 75-86.

DOI: 10.3208/sandf1972.13.4_75

[5] SHERIF M A , ISHIBASHI I ,L EE C D. Earth pressures against rigid retaining walls [J ] . Journal of Geotechnical Engineering ,1982 ,108 (5) : 679-695.

DOI: 10.1061/ajgeb6.0001288

[6] Chen Yekai, Wang Yimin, Xu Riqing, Gong Xiaonan. Numerical analyses of active earth pressure on rigid retaining wall. Chinese Journal of Rock Mechanics and Engineering，2004，23（6): 989-995

[7] Chen Yekai, Wang Yimin, Xu Riqing, Gong Xiaonan. Numerical analyses of passive earth pressure on rigid retaining wall. Chinese Journal of Rock Mechanics and Engineering，2004, 23（6）：980-988

[8] WANG Bao-jian，XIONG Ju-hua，ZHU Bi-tang. Effect of deformation modes of retaining structures on earth pressures．Chinese Journal of Geotechnical Engineering，2006，28（s: 1475-1480

[9] ZENG Qing-you, ZHOU Jian．Analysis of passive earth pressure due to various wall movement by particle flow code (2D)．Rock and Soil Mechanics，2005，26（s）：43-47

[10] Chang M F, Lateral earth pressure behind rotating wall [J]. Canadian Geotechnical Journal, 1997,34(2): 498-509.

[11] Jiang Bo, Ying Hong-wei, Xie Kang-he, et al .Computation of active earth pressure under non-limit state for retaining wall with mode of translation [J].China Journal of Highway and Transport, 2005, 18(2): 24-27.

[12] Yang Taihua, He Huaijian. Displacement-earth Pressure Theory for Cohesive Soil Based on Shear Strength Reduction. Rock and Soil Mechanics, 2009, 30（Supp 2）:185-188

[13] Yang Taihua, He Huaijian. Earth Pressure Calculation Theory Considering Displacement Effects. Rock and Soil Mechanics, 2010, 31（11）:3635-3639

[14] Yang Taihua, He Huaijian, Yu Xiao. Calculation and analysis of Passive Earth Pressure in the Model of RBT Movement with Displacement Effects Considered. Journal of Wuhan University of Science and Technology, 2010, 33（6）:656-659 Author introduction: YangTaiHua, male, born in Hubei province, China in 1976. Work units: Wuhan University of Science and Technology, lecturer and doctor in reading, engaged mainly in the teaching and research on geotechnical engineering. Telephone: [phone], E-mail: [e-mail]
