Analysis of the Dynamic Response of Underground Structures under Internal Explosion

Abstract:

Analytic solution for the dynamic response of underground structure is generally based on the theory of cylindrical shell. The underground structure constructed to resist internal blast is not suitable to be treated as cylindrical shell structure and is difficult to get analytic solution. In this paper, finite element code LS-DYNA is employed to calculate the dynamic response of underground blast-resistant structures exposed to internal blast. Two structures with different thickness buried in four types of surrounding rocks are calculated, and the influence of the surrounding rocks to the dynamic response of underground blast-resistant structures is analyzed.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 1681-1686
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.1681
• Online since: May 2011
• Authors: Peng Fei Ning, De Gao Tang
• Keywords: Dynamic Response, Finite Element, Internal Blast, Surrounding Rock

References

[1] Glenn L A,Kidder R E.Blast Loading of a Spherical Container Surrounded by an Infinite Elastic Medium.Journal of Impact Engineering,1983,50(10): 723-726.

DOI: 10.1115/1.3167136

[2] V.R. Feldgun, A.V. Kochetkov, Y.S. Karinski, D.Z. Yankelevsky. Internal blast loading in a buried lined tunnel, International Journal of Impact Engineering, 35(2008), pages 172-183.

DOI: 10.1016/j.ijimpeng.2007.01.001

[3] Gong SW, Lam KY. Transient response of composite submerged hull subjected to underwater explosive shock. Composite Structures,1998;41:27-37.

DOI: 10.1016/s0263-8223(98)00016-6

[4] WANG Xi , GONG Yu-ning. A theoretical solution for axially symmetric problem in elastodynamics. Acta Mechanica Sinica ,1991 ,7 (3) :275-282

DOI: 10.1007/bf02487596

[5] DING Hao-jiang, WANG Hui-ming, CHEN Wei-qui. A theoretical solution of cylindrical shells for axisymmetric plain strain elastodynamic problems. Applied Mathematics and Mechanics, 2002.23(2):128-134.

DOI: 10.1007/bf02436554

[6] UCRL-TR-215024. C.Nobel, E.Kokko, I.Darnell, T.Dunn, L.Hagler, L.Leininger. Concrete Model Descriptions and Summary if benchmark Studies for Blast Effects Simulations, Lawrence Livermore National Laboratory, July (2005)

DOI: 10.2172/878628

[7] Mmalvar, L.J., Simons, D., "Concrete Material Modeling in Explicit computions," Proceedings Workshop on Recent Advances in Computational Structural Dynamics and High Performance Computing, USAE Waterways Experiment Station, Vicksburg, MS, April 1996, pages 165-194.

[8] Malvar L.J., Crawford, J.E., Wesevich, J.W., Simons, D., "A Plasticy Concrete Material Model for DYNA3D," International Journal of Impact Engineering, Volume 19, December 1997, pages 847-873.

DOI: 10.1016/s0734-743x(97)00023-7

[9] Hallquist J. LS-DYNA3D Theoretical Manual, Livermore Software Technology Corporation, USA, 1994.
