The Study on Mechanical Properties of Single-Bolted Steel-Glulam-Steel Joints

Abstract:

Seven groups, total of 31 single-bolted steel-glulam-steel joints, were tested for their mechanical performance. The mechanical properties of single-bolted steel-glulam-steel connection subjected to a load parallel to the grain have been studied. The failure mode and failure mechanism of bolted connections were discussed in detail. It is shown that the failure mode, bearing capacity, stiffness and ductility of the joint are mainly relative to the thickness of the glulam and the diameter of the bolt. Due to the wide application of bolted steel-glulam-steel connections in engineering, the present work can be taken as a reference in manufacture, and design of modern timber structures.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 204-208
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.204
• Online since: May 2011
• Authors: De Liang Xu, Wei Qing Liu, Ding Zhou, Jian Dong Ding, Ying Lei, Wei Dong Lu
• Keywords: Bearing Capacity, Ductility, Failure Mode, SGS Joint, Single-Bolt, Stiffness

References

[1] Sven Thelandersson. Timber Engineering. [M]. John Wiley &. Sons, Ltd.

[2] Xu Deliang, Liu Weiqing. Rational Wood Arch Axis Fit with Cubic Spline Function[J]. Journal of Jingsu Jianzhu, 2008, (5):36-44.

[3] Johansen K W. Theory of Timber Connections [J]. International Association of Bridge and Structural Engineering, 1949, (9): 249–262.

[4] Morgan Bickerdike., Pierre Quenneville. Predicting the Row Shear Failure Mode in Parallel-to-Grain Bolted Connections. Information on http://www.ewpa.com/Archive/2006/aug /Paper_207.pdf

[5] NDS 1997. National Design Specification for Wood Construction.[M]. National Forest Products Association, Washington D.C., 1997.

[6] ENV 1995. Design of Timber Structures-Part 1: General Rules and Rules for Buildings.[M].Draft(2000).

[7] Recommendation for Limit State Design of Timber Structures (draft) [s]. Architectural Institute of Japan.2003.

[8] Fan Chengmu. Behaviour of Bolted Joint of Timber Structure and Formulate for Calculating – A Discussion on the Formulae for Calculating Bolted Joint of CIB Structure Timber Design Code (Fifth Edition). Journal of Harbin University of Civil Engineering and Architecture 1982, (1): 18-36.

[9] Huang Shaoying, Hong Jing-yuan, Yu Pei-ming. Embedment Strength of Wood Member and Bolt Bearing Strength in the Bolted Joint of Timber Structure [J]. Chongqing Architecture and Civil Engineering Journal, 1986, (1): 11-17.

[10] GB 50005-2003 Code for Design of Timber Structures[S].

[11] ASTM D5652-95. Standard Test Methods for Bolted Connections in Wood and Wood-Based Products [S].
