Analysis on Stress of Inner Steels of Isolator with Large Diameter and Low IRHD Rubber under the Condition of Large Horizontal Deformation

Abstract:

One LNR-D1100 isolator at the stage of large horizontal deformation was analysed by FEM program in this paper, which was applied by press-shear load. The maximum S.Mises stress about inner steels of isolator have been researched. The maximum S.Mises stress will occur in the core upload area, with horizontal shear strain increasing. The core upload area will be diminution with horizontal shear deformation increasing, but the maximum S. Mises stress will be larger and larger. When large horizontal deformation of isolator occurs, there is some out-plane deformation at parts of inner steels near the upmost and downbottom of isolator. Vertical pressure will lend inner steels themself to yield when horizontal shear strain of isolator being loaded.When there is 0 MPa vertical pressure on the isolator, no vertical displacement between the top and the bottom of isolator may be helpful for the maximum S.Mises stress value of inner steels of isolator to decrease.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 2449-2455
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.2449
• Online since: May 2011
• Authors: Chao Yong Shen, Min Hui Zhou, Xiang Yun Huang, Yu Hong Ma, Xue Zhen Zhuang, Jian Min Jin
• Keywords: Finite Element Model (FEM), Inner Steels, Isolator, Large Horizontal Deformation, Press-Shear

References

[1] HUANG Y. Seismic response analysis on base isolated structure[J]. Construction & Design for Project. Vol. 11( 2009), pp.22-25.

[2] LI Y, LI Z L. The influence of isolator characteristics on the seismic response of base-isolated tank[J]. Vol.35(4)(2009), pp.171-176.

[3] LI H, GUAN W W, DU Y F. Fea simulation of temperature properties of natural rubber bearings[J]. Low Temperature Architecture Technology. Vol.31(6)(2009), pp.46-48.

[4] JIANG Y C, LIE S F, YE Z X, LI L. Experimental study on mechanical properties of multi-lead rubber bearing and its explicit finite element analysis[J]. Engineering Mechanics. Vol. 25(7)(2008), pp.11-17.

[5] YAN X Y, ZHANG Y S, WANG H D etc. Experimental study on mechanical properties of three kinds of three-dimensional base isolation and overturn-resistance devices[J]. Journal of Vibration and Shock.Vol.28(10) (2009),pp.49-53.

[6] LI L, YE K, JIANG Y C. Thermal Effect on the Mechanical Behavior of Lead-Rubber Bearing[J]. Journal of Huazhong University of Science and Technology(Urban Science Edition). Vol. 26(3)(2009), pp.1-3.

[7] Mineo Takayama, Hideyuki Tada, Ryuichi Tanaka. Finite-element analysis of laminated rubber bearing used in base-isolation system[J]. Rubber Chemistry and Technology. Vol. 1(65)(1992), pp.46-62.

DOI: 10.5254/1.3538607

[8] International Standard: Elastomeric seismic-protection isolators—Part 3:Applications for buildings —Specifications[C], ISO 22762-3:2005(E), 2005.

DOI: 10.3403/30272327u
