Analysing of the Factors Affecting Pre-Stressing Losing in Pre-Stressing Cable Anchor and Recommending Compensative Measures

Abstract:

After the rock bolt or cable bolt installed in rock and soil mass, as the time goes on, the pre-stress load in bolt maybe losing. Through studying and analyzing the field test data, the factors leading to pre-stress losing are both external and internal factors. The internal factors are cable steel wire loose and rock and soil mass creep deformation. In which the cable steel wire has been pre-tensioned, its affection for load losing is very little. While the rock and soil mass creep deformations have great affection to pre-stress loss. There, if the cable bolt is installed in hard rock, the rock creep deformation will be very little and the load losing in cable bolt will be very few. But if the cable bolt is installed in soft rock and soil mass, the creep deformation will be very much greater than in hard rock, and the pre-stress losing in cable bolt will be very great. The external factors are shocking load, such as blasting load, storm rainfall, temperature change and stress change of anchored rock mass. Through analyzing these affecting factors, some recommend the compensative measures which include choosing appropriate steel wire, pre-tensioning and over-tensioning cable bolt, controlling the blasting rigorous and monitoring the cable long time enough in work time.

• Periodical: Advanced Materials Research (Volumes 261-263)
• Pages: 1891-1897
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.261-263.1891
• Online since: May 2011
• Authors: Xun Guo Zhu
• Keywords: Compensating Measure, Effect Reason, Pre-Stress Anchor Cable, Pre-Stressing Loss

References

[1] Zhang Changtai, Wu Shaohua: Reinforcement of Underground Room by Pre-Stressed Anchor Cable.Metal Mine, Vol. 6 (1996), p.22

[2] Liu Zhiguo, Wang Libang, Sun Yuntian: Pre-stressed Anchorage Technology Utilized in FengMan Dam Reinforcement engineering. The technology of water and electricity, Vol.10 (2000), p.36

[3] Liu Shifeng: Application of Pre-Stressed Anchor Cable to Control Engineering of Unstable Rock Mass in HeQunXia experimental section. Chinese Journal of Rock Mechanics and engineering, Vol.22(2003),p.2734

[4] Li Yinming: Application of MS-20 tension dynameters in slope reinforcement of GEHEYAN ship elevator on QINGJIANG river. Chinese Journal of Rock Mechanics and engineering, Vol.20(2001),p.1823

[5] Zhang Hongbo, Li Yingyong, Song Xiuguang: On pre-stress variation of cable in reinforcement engineering of slope. Journal of Shandong university(nature), Vol.32(2002),p.574

[6] Xiao Baolin: Analysis simply the prestress losing and anchorage affection in Three Gorge ship gate engineer. Yangtze River, Vol.34 (9) (2003), p.6

[7] Zhang Dianji, Tang Ping, Bai Shiwei: Monitoring of research on the effect of prestressed cable reinforcement for jointed rock slope. Chinese Journal of Rock Mechanics and engineering, Vol.22(8)( 2003),p.1276

[8] Zhu Hanya, Sun Hongyue, Wang Huibang etc: Analysis on prestress state of cable applied to rock slope reinforcement. Chinese Journal of Rock Mechanics and engineering, Vol.23 (16) (2004), p.2756

[9] Zhang baojun, Zhang Man, Jin Baozhang: Monitoring on prestressed anchors applied to reinforcement GEHEYAN power station's slope. Journal of Yangtze River Scientific Research Institute,Vol.18(3)(2001),p.36

[10] Li Duanyou, Tang Ping, Li Yiming: Safety monitoring of rock anchor prestress during 1st stage construction of TGP's permanent lock. Journal of Yangtze River Scientific Research Institute. Vol.17 (1) (2001), p.39

[11] Song Maoxin: Field monitoring of prestressed cable's anchorage effect by the rock slope blasting excavation Protection engineering, Vol.(3)(1998), p.74

[12] Tan Zhilin, Li Yanghui: Field test on non-cohesive cable anchor for TGP. Journal of Yangtze River Scientific Research Institute, Vol.16 (4) (1999), p.19

[13] Guo Renqing, Chen Qiming, Hu Wei: 1000kN rock anchor pullout test studying. Journal of Yangtze River Scientific Research Institute, Vol.13 (1996), p.59

[14] Su Xuegui, Li yanbin, Meng Xiusheng: Analysis of the factors affecting prestress losing in prestressed cable anchor. Journal of Xi'an Ming Institute, Vol.19 (1999), p.87

[15] Gao Dashui, Zeng yong: Monitoring analysis on prestress state of anchor cable of high slope of the TGP permanent shiplocks. Chinese Journal of Rock Mechanics and engineering, Vol.20 (5) (2001), p.653
