A Resolution Design of the Energy Conservation Based on Energy Chip CS5460A in Home

Abstract:

Recently, the digital meters have much more development in the worldwide. The CS5460A is a single chip that can measures the energy, and provides the ideal cases for its high-integrated and high-precision. Not only the CS5460A can be applied to measure the power、energy、voltage and current, but also can be integrated with the MCU to avoid the power loss and over-wasted for conserving electric energy in the house. The paper introduces the system designation that it is the resolution of the house conservation energy. The system uses the CS5460A to measure the electric power that the house is costing, and then gets the extra electric power which the AT89S52 does read, at last controls the electrical equipments through the analysis of the power and the action of the relays.

• Periodical: Advanced Materials Research (Volumes 268-270)
• Pages: 1271-1274
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.268-270.1271
• Online since: July 2011
• Authors: Ming Yi Mao, Qian Mo, Qing Fu Huang, Zhi Cheng Chen, Hao Han Qu
• Keywords: AT89S52, Conservation Energy, CS5460A, SPI

References

[1] Xiankai Liu: The Application of energy chip CS5460A, Electrical Measurement & Instrumentation, Vol. 44 (2001), pp.62-64.

[2] Yun ZHU, Xiufan Le and Xuan Gao; The Application of High-precision Single-phase power/energy chip in Electric Parameter Measurement, Electric Power Automation Equipment, Vol. 24 (2004), pp.50-53.

[3] Minqi Zhou and Qian Zhang: The Intelligent Power Control System Based on CS5460A, Modern Electronics Technique, Vol. 1 (2010), pp.167-170.

[4] Shufeng Zhou, Juntao Zou, Weidong Peng: Realize Power and Electric Energy Measurement Using CS5460 and μPD75P3116, Modern Electronics Technique，Vol. 19 (2003), pp.96-98.

[5] Liming He, in: The Design of MCS51 Microcontroller Application System, edtied by Beihang University Press , Beijing (1993), in press.
