Design of Test System for Performance of the Car Vacuum Booster Based on Virtual Instrument Technology

Abstract:

Vacuum booster is an important assembly part of the auto brake system．It influences the driving security directly so that it must be tested whether it reaches the design target and the related standards before leaving factory or in servicing in order to eliminate the driving danger．The virtual instrument based on LabVIEW is a kind of advanced technique with powerful analytical ability, flexible configure and rich tool modules providing many advantages for engineering test in virtue of computer and digital signal processing．The thesis based on its advantage to teat the performance of vacuum booster in a simulated work conditions, which is based on the National Standard of GB12676-1999, QC/T 307-1999 and QC/T 308-1999.The test system has been designed with the integration of hydraulic pressure control technology, data acquirisition technology, electro mechanics and virtual apparatus．The result indicated that the test system was reliable and the data acquirisition was accurate．Especially, the system could simulate the instance of auto in the state of long slope braking or frequent braking and has certain superiority compared with existing equipment．

• Periodical: Advanced Materials Research (Volumes 268-270)
• Pages: 1902-1908
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.268-270.1902
• Online since: July 2011
• Authors: Da Ming Huang, Chun Lan Yang, Ling Fang Wu, Zhi Feng Ma, Qi Hong Yao
• Keywords: Performance Test, System Design, Vacuum Booster, Virtual Instrument (VI)

References

[1] ZhaoMin, MaoYali. Brake power test system [J]. journal of Shenyang engineering university (natural science edition), 2006, 2 (1): 89-91.

[2] WangJinqiao, Yanxiang'an, CaoYuping. Auto vacuum booster performance test device [J]. journal of hydraulic and pneumatic transmission, 2003 (11): 62-64.

[3] ZhuChen. Car vacuum booster performance test device [J]. afs college of Inner Mongolia agriculture journal, 2008, 2. 9 (2): 141-143.

[4] Of national mechanical GongYeJu. T307-1999 QC/vacuum booster technical standard [S] / / automobile industry standard of the People's Republic of China. Beijing: national standardization press, (1999).

[5] Dynasty, PanShuang summer. King car braking performance testing methods and virtual instrument research. Mechanical and electrical engineering [J] 2006, 6: 14-16.

[6] JiangHaobin, packet is peak, YunLiang. Based on virtual instrument technique multi-function plate-type car testing system development [J]. journal of instrument technology and sensor, 2009 (12): 26-29.

[7] ZhangShutuan Asia mansion etc. Based on the LabVIEW aircraft electric parameters test system design [J]. journal of electronic measurement technology, 2008, 3 1 (6): 97-99.

[8] ZhangYaodong, LiuWenbo etc. Flight parameter recording system comprehensive test-bed design [J]. j Jamusi university journal (natural science edition), 2009, 27 (2): 185-187.

[9] GeQingzhi, ZhangXiangwen, XuYong. Virtual instrument technology in the tire pressure monitoring system application [J]. Computer measurement and control, 2009, 1, 7 (6).

[10] GaoDongwei, LiHongnan etc. Based on virtual instrument technique for structural health monitoring system development [J]. computer, 2009, 2, 1 (10): 2889-2894.

[11] LiBo, based on virtual instrument technique fault diagnosis expert system realization, [J]. Computer measurement and control, 2009, 1, 7 (7) : 1258-1260.

[12] LiTing, DuEnxiang etc. Of virtual instrument autoloader faults detection platform design [J]. journal of firepower and command and control, 2008: 100-106.

[13] Zhu YuQing, WuWeibin etc. Based on virtual instrument technique engine dynamometer system [J]. Journal of Guangxi university (natural science edition), 1992 (4): 310-314.
