A Time-Frequency Analysis for Deflection of a Cutting Disc Used in Sawing Process

Abstract:

Cutting discs are affected by various forces which cause stresses and deflections on the discs. Lateral deflection is one of the most frequent. It is important to know that major lateral deflections can cause undesired failures on the disc. In this study, time/frequency analysis of deflection on a cutting disc used in metal sawing process has been performed. The deflections are measured by using a laser device called KEYENCE and data recorded during the cutting process. The data sequence is converted into frequency domain with Fourier transform techniques and frequency components are analyzed. It is observed that some frequency components carry important information about the process. Using this information, the starting and ending times of cutting are determined and presented.

• Periodical: Advanced Materials Research (Volumes 268-270)
• Pages: 847-852
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.268-270.847
• Online since: July 2011
• Authors: Ismail Ucun, Fatih Onur Hocaoğlu, Sukru Gorgulu
• Keywords: Cutting Disc, Cutting Process, Deflection, Discrete Fourier Transform, Fast Fourier Transform (FFT), Spectrogram Analysis

References

[1] J. Kopac, S. Sali: Tool wear monitoring during the turning process, Journal of Materials Processing Tech., 113, (2001), pp.312-316.

[2] O.B. Abouelatta, J. Madl: Surface roughness prediction based on cutting parameters and tool vibrations in turning operations, Journal of Materials Processing Tech., 118, (2001), pp.269-277.

DOI: 10.1016/s0924-0136(01)00959-1

[3] X. Li, X.P. Guan: Time-frequency-analysis-based minor cutting edge fracture detection during end milling, Mechanical Systems and Signal Processing, 18, (2004), pp.1485-1496.

DOI: 10.1016/s0888-3270(03)00096-7

[4] P. Bhattacharyya, D. Sengupta, S. Mukhopadhyay: Cutting force-based real-time estimation of tool wear in face milling a combination of signal processing techniques, Mechanical Systems and Signal Processing, 21, (2007), 2665-2683.

DOI: 10.1016/j.ymssp.2007.01.004

[5] A. Sarhan, R. Sayed, A.A. Nassr, R.M. El-Zahry: Interrelationships between cutting force variation and tool wear in end-milling, Journal of Materials Processing Tech., 109, (2001), 229-235.

DOI: 10.1016/s0924-0136(00)00803-7

[6] H. Jiang, X. Long, G. Meng: Study of the correlation between surface generation and cutting vibrations in peripheral milling, Journal of Materials Processing Tech., 208, (2008), pp.229-238.

DOI: 10.1016/j.jmatprotec.2007.12.127

[7] F. O. Hocaoğlu, M. Fidan, Ö.N. Gerek: A Novel Fourier Based Solar Radiation Model, ICIC Express Letters , 3, (2009) pp.1101-1106.

[8] W. K. Jenkins: Fourier Series, Fourier Transforms, and the DFT, Digital Signal Processing Handbook, Editors: Vijay K. Madisetti and Douglas B. Williams Boca Raton: CRC Press LLC, (1999).

DOI: 10.1046/j.1365-2818.1999.00607.x

[9] B. Boashash, Editor: Time-Frequency Signal Analysis and Processing, A Comprehensive Reference, Elsevier Science, Oxford, (2003).
