Numerical Simulation on Fluid Field of Different Structure Supersonic Atomizing Nozzle

Abstract:

A supersonic atomizing nozzle is the quite vital component in manufacturing superfine copper powders. The performances of the nozzle have a extremely major influence on the properties of copper powders. Base on the manufacturing technological conditions and the structural features of supersonic nozzle, the mathematical models of fluid field in the supersonic nozzle can be established. According to the method of computational fluid dynamics, the control equation is dispersed. The gridding is created by the means of free division. The finite element equations are set up by Galerkin. Then the impact of nozzle structures on airflow is showed. In the same situation of fluid parameters, the out velocity becomes higher by changing the nozzle structure. The result proves that quadric accelerating nozzle is better.

• Periodical: Advanced Materials Research (Volumes 268-270)
• Pages: 869-874
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.268-270.869
• Online since: July 2011
• Authors: Xiao Bo Liu, Yong Xue Li
• Keywords: Atomizing Nozzle, Fluid Field, Numerical Simulation, Supersonic

References

[1] P Y Huang: Methods of Powder Metallurgy. (Metallurgy Industry Press, Beijing 1997) (in Chinese).

[2] D D Singh, S Dangwal: Journal of Material Sciences. Vol. 41(2006), p.3853.

[3] R Unal: Journal of Materials Processing Technology. Vol. 180(2006), p.291.

[4] R Ling, X A Dang, X J Zhao, X H Liu: Nonferrous Metals, Vol. (2008), p.36(in Chinese).

[5] H P Chen: Computational Fluid Mechanics. ( China Water Power Press, Beijing 1995) (in Chinese).

[6] Y Xu, S S Dang, R X Hu: Course in Fluid Field Analysis Cases in ANSYS11. 0/FLOTRAN. (Mechanical Industry Press, Beijing 2009) (in Chinese).
