Research on Six DOF Vertical Vibration Model of a Four Roller Hot Strip Rolling Mill Stand

Abstract:

A lumped mass model with six degrees of freedom for the vertical vibration of four roller hot strip rolling mill stand was proposed, while its natural frequencies were calculated by MATLAB software. The numerical calculation results were proved more accurate through field vibration test. This vertical vibration model can be applied for dynamic simulation and structural dynamic modification with important theoretical and practical significance in mastering the vibration characteristics of four-roll mill, avoiding vertical self-excited vibration and improving production efficiency.

• Periodical: Advanced Materials Research (Volume 279)
• Pages: 301-306
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.279.301
• Online since: July 2011
• Authors: Wei Jin Ma, Jun Yuan Wang, Feng Lan Li, Zhi Qiang Zeng, Deng Hong Xiao, Shi Bo Xiong
• Keywords: Hot Strip Rolling Mill Stand, Modal Frequency, Numerical Computing, Vertical Vibration Model

References

[1] Lian Jiachuang, etc: Research on natural frequency of four roller mill horizontal vibration, Chinese Journal of Mechanical Engineering, 19, 3(1983), pp.1-10.

[2] Yang Qijun, Lian Jiachuang: Stability analysis of self-excited vertical vibration of high speed cold strip mills by numerical method. Journal of Vibration and Shock, 15, 3(1996), pp.16-21.

[3] Cai Ganwei, Duan Jian, Yi Youping, Zhong Jue, Chen Peilin: A finite element model for dynamic analysis of rolling mill. Chinese Journal of Mechanical Engineering, 36, 7(2000), pp.66-68.

DOI: 10.3901/jme.2000.07.066

[4] Tang Honghai, Li Yourong, Liu Anzhong: Finite element analysis of four-high mill stand. Journal of Wuhan University of Science and Technology, 32, 2(2009), pp.149-153.

[5] Xiao Yunping, Liu Yilun, Zhou Xian: Simulation and analysis on the vertical vibration of four-high rolling mill stand. Machinery, 35, 1(2008), pp.17-18.

[6] Ma Weijin, Li Fenglan, Xiong Shibo: Analysis and Diagnosis of Self -Excitation-Vibration of Hot Rolling Mill, Journal of Vibration. Measurement & Diagnosis, 26, 4(2006), pp.261-264.

[7] Ma Weijin, Wang Junyuan, Li Fenglan etc: Experimental modal analysis of roller gap sensor structure on hot rolling mill. Advanced Materials Research Vol. 97-101 (2010), pp.4328-4331.

DOI: 10.4028/www.scientific.net/amr.97-101.4328

[8] Ma Weijin, Xiong Xiaoyan, Li Fenglan, etc: Modal parameter testing of roller gap sensor structure on hot rolling mill. Chinese Journal of Mechanical Engineering, 45, 7(2009), pp.259-264.

DOI: 10.3901/jme.2009.07.259

[9] Kazushige Ishino, Kazuhisa Kabeya, Takao Yoshikawa: Vibration analysis of chatter in cold rolling mill (Theoretical study on self-excited vibration by a Two-DOF mass-spring-damper model). Transactions of the Japan Society of Mechanical Engineers, code C, 687, 69(2003), pp.2975-2982.

DOI: 10.1299/kikaic.69.2975

[10] I.S. Yun, W.R.D. Wilson, K. F. Ehmann: Review of chatter studies in cold rolling. International Journal of Machine Tools & Manufacture Vol. 38(1998), pp.499-1530.

DOI: 10.1016/s0890-6955(97)00133-8
