Dynamic Performance Analysis on High-Speed Railway Continuous Girder Bridge

Abstract:

The dynamic performance of continuous girder under the train in a series of speed is studied through examples, and the main conclusions are given in the following. The resonance mechanism of continuous girder is similar to simply supported beam. The vehicle wheel load forms regular moving load series, which induces periodical action and resonance of the bridge. The damping ratio of bridge itself has less effect on the amplitude at the loading stage, but significant effects appear when the load departs from the bridge. The count of continuous spans also has less impact on the dynamic coefficients, so three continuous spans can be adopted for calculation and analysis. Span and fundamental frequency have significant influence on dynamic coefficients of bridge structures. To extend the span of the bridge structure can reduce the dynamic coefficient while keeping its frequency invariant. The fundamental frequencies of different bridges are corresponding to certain resonant speeds, which calls for the attention in the design.

You might also be interested in these eBooks

Green Building Materials and Energy-Saving Construction

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 280)

Pages:

186-190

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.280.186

Citation:

Cite this paper

Online since:

July 2011

Authors:

Shou Tan Song, Ji Wen Zhang, Xin Yuan

Keywords:

Continuous Beam, Dynamic Coefficient, Railway Bridge, Resonance

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] XIA He, GUO Wei-wei, ZHANG Nan. Analysis of Resonance Mechanism and Conditions of Train-Bridge System [J]. Journal of the China Railway Society, Vol. 28 No. 5 October 2006. 52-58(in Chinese).

Google Scholar

[2] LIANG Bo, LUO Hong, SUN Chang-xin. Simulated Study on Vibration Load of High Speed Railway [J]. Journal of the China Railway Society, Vol. 28 No. 4 August 2006. 39-44(in Chinese).

Google Scholar

[3] WANG Qing-bo, WANG Sheng, XU Ke-bin, XIA He. Dynamic Responses of High Speed Railway Continuous Bridge [J]. Journal of Northern Jiao Tong University, Vol. 21 No. 4 August 1997. 399-404 (in Chinese).

Google Scholar

[4] SU Mu-biao, LI Jian-zhong, ZOU Zhen-zhu. Analysis of the Factors influencing vertical Resonance of Simply Supported Railway Girders [J]. Engineering Mechanics, Vol. 20 No. 4 August 2003. 60-66 (in Chinese).

Google Scholar

[5] Clough R W, Penzien J. Dynamics of Structure [M]. New York: McGraw. Hill Inc, (1993).

Google Scholar

[6] XIA He, ZHANG Nan. Reaction of Train-Bridge System [M]. Second Edition. Beijng: Science Press, 2005. (in Chinese).

Google Scholar
