Gas Barrier Properties of SiO_X Films Deposited by RF Magnetron Co-Sputtering

Abstract:

SiO_x barrier films were deposited on poly (ethylene terephthalate) (PET) by radio frequency (RF) magnetron co-sputtering with double targets. The films deposited by co-sputtering were denser and smoother because different energy particles sputtering from double targets grew small islands to weaken shadowing effect which greatly reduce the interval gaps. The water vapor and oxygen transmission of SiO_x films deposited by co-sputtering decreased to 0.31 cc/m²/day, 0.27 g/m²/24h respectively.

• Periodical: Advanced Materials Research (Volumes 284-286)
• Pages: 48-52
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.284-286.48
• Online since: July 2011
• Authors: Zhuang Liu, Lin Zhu, Jing Lin, Zhi Hui Sun
• Keywords: Barrier, Co-Sputtering, Silicon Oxide

References

[1] S.Iwamori, Y.Gotoh, K.Moorthi, Silicon oxide gas barrier films deposited by reactive sputtering, Surface and Coatings Technology 166(2003)24-30.

DOI: 10.1016/s0257-8972(02)00769-7

[2] H. Miyazaki, T. Goto, SiOx films prepared using RF magnetron sputtering with a SiO target, Journal of Non-Crystalline Solids 352(2006)329-333.

DOI: 10.1016/j.jnoncrysol.2005.12.008

[3] M. Deilmann, S Theiß, P.Awakowicz, Pulsed microwave plasma polymerization of silicon oxide films: Application of efficient permeation barriers on polyethylene terephthatate, Surface and Coatings Technology 202(2008)1911-1917.

DOI: 10.1016/j.surfcoat.2007.08.034

[4] K. Lau, J. Weber, H. Bartzsch, P. Frach, Reactive pulse magnetron sputtered SiOxNy coatings on polymers, Thin solid films 517(2009)3110-3114.

DOI: 10.1016/j.tsf.2008.11.084

[5] Y.G. Tropsha, N.G. Harrvey, Activated rate theory treatment of oxygen and water transport through silicon oxide poly(ethylene terephthalate) composite barrier structures, Journal of Physical Chemistry B 101(1997)2259-2266.

DOI: 10.1021/jp9629856

[6] A.P. Roberts, B.M. Henry, A.P. Sutton, C.R.M. Grovenor, G.A.D. Bringgs, T. Miyamoto, M. Kano, Y. Tsukahara, M. Yanaka, Gas permeation in silicon-oxide/polymer (SiOx/PET) barrier films: role of the oxide lattice, nano-defects and macro-defects, Journal of Membrane Science, 208(2002)75-88.

DOI: 10.1016/s0376-7388(02)00178-3

[7] H. Bartzsch, D. Glöß, B. Böcher, P. Frach, K. Goedicke, Properties of SiO2 and Al2 O3 films for electrical insulation applications deposited by reactive pulse magnetron sputtering, Surface and Coatings Technology 174-175(2003) 774-778.

DOI: 10.1016/s0257-8972(03)00384-0

[8] J. Fahlteich, M. Fahland, W. SchÖnberger, N. Schiller, Permeation barrier properties of thin oxide films on flexible polymers substrates, Thin solid films 517(2009)3075-3080.

DOI: 10.1016/j.tsf.2008.11.089

[9] C. Gravalidis, M. Gioti, A. Laskarakis, S. Logothetidis, Real-time monitoring of silicon oxide deposition processes, Surface and Coatings Technology, 180-181(2004)655-658.

DOI: 10.1016/j.surfcoat.2003.10.141

[10] N. Tomozeiu, E.E. van Faassen, W.M. Arnoldbik, A.M. Vredenberg, F.H.P.M. Habraken. Structure of sputtered silicon suboxide single and multi layers, Thin Solid Films 420-421(2002) 382-385.

DOI: 10.1016/s0040-6090(02)00842-8

[11] A. Palmero, N. Tomozeiu, A.M. Vredenberg, W.M. Arnoldbik, F.H.P.M. Habraken, On the deposition process of silicon suboxides by a RF magnetron reactive sputtering inAr-O2 mixtures theoretical and experimental approach, Surface and Coatings Technology 177-178(2004)215-221.

DOI: 10.1016/j.surfcoat.2003.09.035

[12] Lin M-C, Tseng C-H, Chang L-S, Wuu D-S, Characterization of the silicon oxide thin films deposited on polyethylene terephthalate substrates by radio frequency reactive magnetron sputtering, Thin solid films 515(2007)4596-4602.

DOI: 10.1016/j.tsf.2006.11.039
