Shape Finding Analysis of Membrane Structures Based on Real Material Property

Abstract:

In order to obtain a real shape of membrane structure, a new shape finding method was developed based on real material property. The curved shape is first obtained by raising the control points above the projection plane. The convergence was improved using pseudo material properties to get a preliminary shape, and then the real properties to get the final shape. A large number of examples were analyzed to verify the validity and practicality of this method. The results showed that the final curved surface after the second shape finding process was always quite similar to the first one. Moreover the curved surface obtained after the second shape finding process is accurate and will be realized in real.

• Periodical: Advanced Materials Research (Volumes 287-290)
• Pages: 2207-2212
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.287-290.2207
• Online since: July 2011
• Authors: Wei Guo Yang, Xing Po Li
• Keywords: Membrane Structure, Nonlinear, Real Material Properties, Shape Finding

References

[1] Barnes M R: of Space structure, Vol.14 (1999), pp.19-24

[2] Meek J L: of Space structure , Vol.14 (1999),pp.39-45

[3] Chuanxi Xu, Ruojun Qian. Non-linear finite element analysis for tension only membrane tructure[A].In: Sixth Space Structure Academic Conference Proceedings [C]. Guangzhou: 1992:580-586. (in Chinese)

[4] Weiguo Yang. Theoretical Problems in Membrane Structure Design and Projects Practice：[Ph.D. Dissertation]. Northern Jiaotong University, Beijing(2002) (in Chinese)

[5] Yang Xiang, Jun Li and Shizhao Shen: Space Structure, Vol.9 (1999)：pp.19-27 (in Chinese)

[6] Chunjiang Wang. Common Introduction of Membrane Structure Shape Finding Theory. Tenth Space Structure Academic Conference Proceedings. Beijing: Publishing House of Construction Material Industry, 2002，385-391(in Chinese)

[7] T.S. Loong, H. A Razak, Z. Ismail and C.K. Keong, Experimental and numerical form –finding of membrane structures,Asian journal of civil engineering (Building and housing) VOL. 8, NO. 1 (2007).pp.1-12

[8] Yongqiang Gao, Xiuhong Wang, Dongrnei Liu, Form-finding Analysis and Implementation of Cable-reinforced Membrane Structure Based on ANSYS,2010 International Conference on E-Health Networking, Digital Ecosystems and Technologies [C],Shenzhen China, pp.458-460

DOI: 10.1109/edt.2010.5496535

[9] Liu Xuelin, Studies on Form-finding of Cable Membrane Structures by FEMOL, [Ph.D. Dissertation]. Tsinghua University, Beijing( 2009)

[10] Beichen Liu: Calculational Mechanics. Publishing House of Mechanism Industry, pp.203-350 Beijing ( 1994) (in Chinese)

[11] Xiaobin Ye: Establishment of Membrane Structure Analysis Theory on the Basis of Curved Surface Membrane Element. [Ph.D. Dissertation]. Tianjin University Tianjin (1999). (in Chinese)

[12] Li Zhang. Research on the Shape Determination of Tensile Structure: [Ph.D. Dissertation]. Shanghai: Tongji University（2000）. (in Chinese)
