Finite Element Analysis and Structural Improvement of Farm Engine Connecting Rod

Abstract:

In this paper, with the ANSYS, stress distribution and safety factor of connecting rod were analyzed by using 3D finite element method. The results show that the exposed destructive position is the transition location of big end and connecting rod shank at maximum compression condition and maximum stretch condition. Maximum stress is 353MPa. Safety factor is 2.22. Maximum deformation is 0.0728mm. Based on the analysis, the structure of connecting rod is improved. Safety factor of connecting rod increase 12%.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 2413-2416
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.2413
• Online since: July 2011
• Authors: Bin Zheng, Yong Qi Liu, Rui Xiang Liu, Jian Meng
• Keywords: Connecting Rod, Finite Element Analysis (FEA), Safety Factor, Stress Distribution

References

[1] J.C. Zhang, X.H. Li, and G. Sun: Tractor & Farm Transporter Vol. 33(2006), p.27. In Chinese

[2] Z.J. Tang, Z.X. Zuo, and R.H. Zhang: China Mechanical Engineering Vol. 15(2004), p.365. In Chinese

[3] W.F. Dai, W.X. Fan, and Z.J. Cheng: Small Internal Combustion Engine and Motorcycle Vol. 37(2008), p.48. In Chinese

[4] K. HO-LE: Computer Aided Design Vol. 20(1998), p.27.

[5] S.T. Xiong: Small Internal Combustion Engine and Motorcycle Vol. 30(2001), p.22. In Chinese

[6] D.H. Tu, S.L. Jiang, and M.L. Cao: Transactions of CSICE Vol. 22(2004), p.176. In Chinese

[7] H. Wu, F. Wang, and H.Y. Gan: Chinese Internal Combustion Engine Engineering Vol. 24(2003), p.31. In Chinese
