FEM Analyses on Stress and Deformation of a C-Type Expansion Bolt

Abstract:

The C-type expansion bolt is a new kind and new structural bolt. It has superior compatibility to the soft rock and the big distorted tunnel. In order to study its stress, deformation and interaction mechanism, large distortion calculations and analyses have been carried out on the bolt by FEM (finite element method), especially with the ANSYS software, based on the updated Lagrangian law. The results show that the maximum stress and deformation of the section and body of the bolt meets the anchoring requirements. The bolt meets the required anchoring performance and anti-drawing performance. The paper provides some basis for its design, application and anchoring stress analysis.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 2425-2428
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.2425
• Online since: July 2011
• Authors: Zhong He Chen, Wei Qiang Wang, Ming Zhang, Ning Ning Dong
• Keywords: C-Type Expansion Bolt, Finite Element Model (FEM), Large Distortion Calculation, Stress and Deformation

References

[1] Chen Z H, Wang W Q, Zhang L W. Analysis of anchoring mechanism of flexible inner pressured bolt.[J].Journal of Liaoning Technical University. 2006,25(5):699-701

[2] Chen Z H. Study on the flexible inner pressured bolt and its anchoring and failure [Ph.D. dissertation].Jinan: Shandong University doctorate paper.2006,31-43,61-71 (In Chinese)

[3] Chen Z H, Wang W Q, Zhang L W. FEM analyses of stress and deformation of a flexible inner pressure bolt. .Journal of China University of Mining & Technology, 2008, 18(04): 584-587

DOI: 10.1016/s1006-1266(08)60299-0

[4] Yan X Q. Large deformation finite element analysis for rubber matrix composite structures [J].Chinese Journal of Computational Mechanics.2002,19(2):476-481

[5] Qan H S, Gao Y C. Large Deformation Character of Two Kinds of Models for Rubber[J]. Int. J. Eng. Sci. 2001, (39): 39-51

[6] Song E X, Qiu Y. Finite element analysis of composite soil nailing for excavation support [J]. Rock and Soil Mechanics, 2001, 22(3): 241-245.

[7] Zhang C H. ANSYS 8.0 structure and example analysis [M].Beijing: Mechanical industry publishing house, 2005, 344-354 (In Chinese)

[8] Zhu Y L, Kong X J, Zou D G. Nonlinear finite element analysis of prestressed anchor flexible retaining for deep excavation [J]. Rock and Soil Mechanics, 2005, (02): 324-327

[9] Bai J B,Hou C J. Control Principle of Surrounding Rock in Deep Roadway and Its Application. Journal of China University of Mining & Technology, 2006, 35(02): 145-148

[10] Brünig, Michael. Numerical Analysis and Modeling of Large Deformation and Necking Behavior of Tensile Specimens[J].Finite Elements in Analysis and Design, 1998,28(4):303-3

DOI: 10.1016/s0168-874x(97)00042-5
