The Vibration Analysis and Modal Experimental Study of High Speed Motorized Spindle

Abstract:

Vibration testing and modal experiment under the different speed are carried out to the high speed motorized spindle whose maximum speed is 60 000 rpm. Time domain waveform and spectrum of motorized spindle’s radial vibration acceleration are obtained under the unload state. Through calculating and analyzing, the vibration velocity and the testing point which generates the maximum vibration velocity are found out. Then motorized spindle is validated whether it accords with the requirements of high-precision manufacture. And the correctness of the vibration testing method is also verified. Primary reasons of the motorized spindle’s vibration are put forward. The first five steps natural frequencies of motorized spindle test-bed are gained by appropriate ways to checkout if the test-bed in the resonance region.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 3078-3082
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.3078
• Online since: July 2011
• Authors: Jie Meng
• Keywords: High Speed Motorized Spindle, Modal Analysis, Operational Modal, Vibration Experiment

References

[1] A.Boglietti, P.Ferraris, M.Lazzari, et al, Test procedure for very high speed spindle motors, Industry Applications Society Annual Meeting. 1 (1990) 102-108.

DOI: 10.1109/ias.1990.152171

[2] S. Vafaei, H. Rahnejat, R. Aini, Vibration monitoring of high speed spindles using spectral analysis techniques, Machine Tools & Manufacture. 42 (2002) 1223–1234.

DOI: 10.1016/s0890-6955(02)00049-4

[3] Xiaohua Zhang, Stochastic Subspace Identification and Application of Structures under Ambient Vibration, Fuzhou University, 2005. (In Chinese)

[4] Chang Deng, The Modal Experiment Analyse of the Large-span Structurers Based on Environment Encourag, Southeast University, 2005. (In Chinese)

[5] Xiaolan Sun, Wang Taiyong, Operating Modal Parameter Identification of Vibrating Structure Based on Correlation Function, Journal of Tianjin University. 40 (2007) 503-506. (In Chinese)

[6] James G.H. III, Carne T.G., Laufer J.P, The Natural Excitation Technique (NExT) for Modal Parameter Extraction from Operating Structures, Analytical and Experimental Modal Analysis. 10 (1995) 260-277.

[7] M.Abdelghani, M.Verhaegen, Comparison Study of Subspace Identification Methods Applied to Flexible Structures, Mechanical Systems and Signal Processing. 12 (1998) 679-692.

DOI: 10.1006/mssp.1998.0169

[8] N.B. Moller, Herlufsen, S.Gade, Stochastic Subspace Identification Techniques in Operational Modal Analysis, Proceedings of 1st IOMAC Conference, Copenhagen, Denmark. (2005) 26-27.

[9] Wenchong Fan, Operational Modal Identification of Machine Centers System, Kunming University of Science and Technology, 2005. (In Chinese)
