An Experimental Investigation of the Laser Milling Process for Polycrystalline Diamonds

Abstract:

An experimental study of the pulsed laser milling process for a sintered polycrystalline diamond is presented. The characteristics and quality of the cavities machined with a Yd laser under different pulse energies, pulse overlaps, scan overlaps and numbers of passes are discussed, together with the effects of these parameters on the cavity profile, depth of cut and surface roughness. A statistical analysis is also presented to study the relationship between the process parameters and surface roughness. It shows that the optimum pulse overlap and pulse energy may be used to achieve good surface finish, whereas scan overlap and number of passes can be selected to improve the depth of cut without much effect on the surface finish.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 810-815
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.810
• Online since: July 2011
• Authors: Qi Wu, Jun Wang
• Keywords: Diamond Tool, Laser Milling, PCD, Process Parameter, Surface Finish

References

[1] B. Kennedy, Toolmakers combine technologies to meet growing demand for PCD tools. Cutting Tool Engineering, 2010. 62(12): pp.48-49+52-54.

[2] M.U. Islam, Advanced Performance Materials, 1996. 3(2): pp.215-238.

[3] I.P. Tuersley, A. Jawaid, and I.R. Pashby, Review: Various methods of machining advanced ceramic materials. Journal of Materials Processing Tech., 1994. 42(4): pp.377-390.

DOI: 10.1016/0924-0136(94)90144-9

[4] P.M. Harrison, M. Henry, I. Henderson, and M. Brownell, Laser milling of metallic and non-metallic substrates in the nanosecond regime with Q-switched Diode Pumped Solid State lasers. 2004.

DOI: 10.1117/12.548819

[5] M.U. Islam and G. Campbell, Laser machining of ceramics: a review. Materials and Manufacturing Processes, 1993. 8(6): pp.611-630.

DOI: 10.1080/10426919308934870

[6] S.R. Vatsya, E.V. Bordatchev, and S.K. Nikumb, Geometrical modeling of surface profile formation during laser ablation of materials. J App. Phy., 2003. 93(12): pp.9753-9759.

DOI: 10.1063/1.1575495

[7] J. Meijer, K. Du, A. Gillner, D. Hoffmann, V.S. Kovalenko, T. Masuzawa, A. Ostendorf, R. Poprawe, and W. Schulz, CIRP Annals - Manufacturing Technology, 2002. 51(2): pp.531-550.

DOI: 10.1016/s0007-8506(07)61699-0

[8] V.I. Konov, F. Dausinger, S.V. Garnov, S.M. Klimentov, T.V. Kononenko, and O.G. Tsarkova, Ablation of ceramics by UV, visible, and IR pulsed laser radiation. 1997.

DOI: 10.1117/12.273722

[9] R.L. Mason, R.F. Gunst, and J.L. Hess, Statistical Design and Analysis of Experiments - With Applications to Engineering and Science (2nd Edition), John Wiley & Sons.

[10] T.A. Davis, and J. Cao, Effect of laser pulse overlap on machined depth. 2010.

[11] F.W. Dabby and U.C. Paek, High- intensity laser- induced vaporization and explosion of solid material. IEEE Journal of Quantum Electronics, 1972. QE-8(2 pt 2): pp.106-111.

DOI: 10.1109/jqe.1972.1076937
