The Measurement Correction of MEMS Gyroscope Based Interlaced Kalman Filtering

Abstract:

To correct the angular rate measurement error of MEMS gyroscopes for tactical missile, this paper proposes use of dynamics correspondence between the rudder control torque and the missile body attitude to build the state equation of system, which is more realistic and precise than the description for the actual missile attitude change with low-pass filter. In order to avoid errors in the linearization for nonlinear equations and reduce the filtering computation complexity, the Interlaced Kalman Filtering is applied to achieve the pseudo-linear state equation with coupling terms, which effectively reduce the computation complexity. Finally, the semi-physical simulation with the three-axis MEMS IMU and Electro-Servo verified that the algorithm significantly improved the angular rate measurement accuracy of the low-precision MEMS gyroscope.

• Periodical: Advanced Materials Research (Volumes 301-303)
• Pages: 1083-1088
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.301-303.1083
• Online since: July 2011
• Authors: Jun Jie Lu, Jun Zhou, Xiao Dong Lu, Xiao Jun Liu
• Keywords: Attitude Dynamic Equations, Error Correction, Interlaced Kalman Filtering, MEMS Gyroscope

References

[1] He Kunpeng. Parametric Identification and Error Compensation of MEMS Inertial Sensors and IMU. Harbin Engineering University, 2009. 3.

[2] JIN Guangming, ZHANG Guoliang, CHEN Linpeng, TIAN Qi. Research on filter method and model of MEMS gyro static drift. Transducer and Microsystem Technologies, 2007, 26(11)：48-50.

[3] LI Jie, LIU Jun, ZHANG Wendong, YANG Wei. Research on Random Error Compensating Methods for MEMS Gyroscope. Journal of North University of China(Natural Science Edition), 2009, 30(4): 381-385.

[4] Yang K H, Shi Y G, Ji J, et al. Attitude determination system with low cost magnetic and MEMS inertial sensors．Journal of Chinese Inertial Technology, 2008, 16(5): 556-562.

[5] Marcelo C. A, Douglas E. Ehiers. Suppression of Gyroscope Noise Effects in Pointing and Tracking Systems. 1994, SPIE Vol. 2221, 402-413.

[6] LI Hanzhou, LIU Xiuyan. Error compensation technique for SINS with dynamically tuned gyroscope. Journal of Chinese Inertial Technology, 2007, 15(4)：403-406.

[7] Yang K H, Shi Y G, Ji J, et al. Attitude determination system with low cost magnetic and MEMS inertial sensors．Journal of Chinese Inertial Technology, 2008, 16(5): 556-562.

[8] Kortunov V I, Dybska Y I, Proskura G A, et al. Integrated mini INS based on MEMS sensors for UAV control. IEEE Aerospace and Electronic Systems Magazine, 2009, 24: 41-43.

DOI: 10.1109/maes.2009.4772754

[9] Shen, S C, Chen, C J, Huang, H. J, et al. Evaluation of MEMS inertial sensor module for underwater vehicle navigation application[C]. Mechanic Automation and Control Engineering, 2010 International Conference on Digital Object Identifier, 2010, 5-10.

DOI: 10.1109/mace.2010.5535510

[10] He Yuanjun, Lu Xiaodong, Lv Chunhong. Calculation and Correction Method for MEMS Strap-down Inertial Navigation System. Computer Measurement & Control, 2010, 18(6): 1364-1366.

[11] Guo Caifa, Zhao Xing, Cai Hong. Analysis of Algorithm for INS/Geomagnetic Integrated Navigation Under Colored Noise. Journal of Spacecraft TT&C Technology, 2010, 29(4): 84-88.
