Research on Harmonic Detection Methods of Electrified Railway

Abstract:

This paper introduces the characteristics of the traction power system of electric railway, and explores the harms to the power system caused by electric railway and the necessity of harmonic suppression of traction power supply system. In order to achieve real-time detection and compensation for harmonic waves of electric railway traction power system, this paper provides an improved harmonic detection method with initial compensating angle of delay time. Detection method is simple, and has better real-time, it can be used to detect selective harmonic for electrified railway.

• Periodical: Advanced Materials Research (Volumes 301-303)
• Pages: 1740-1743
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.301-303.1740
• Online since: July 2011
• Authors: Xiang Zheng Xu, Wei Wan
• Keywords: Electrified Railway, Harmonic Detection, Harmonic Suppression, Power Quality (PQ)

References

[1] He Changhong. Status and Improvement Measures of Power Quality for World High-speed Electrified Railway. Electrified Railway, vol. 6(2008), pp.1-5.

[2] Zhang Dinghua, Gui Weihua, Wang Weian, Wang Xiaofang. Study and Application of a New Power Quality Combined Compensation System for Electrified Railway. Transactions of China Electrotechnical Society, vol. 24(2009), pp.189-194.

DOI: 10.1109/chicc.2008.4604957

[3] Ling Wang. Seveal Single-phase Circuit Improved Harmonic and Reactive Current Detection Methods. Jiangsu University, (2009).

[4] Wang Hao, Zhang Chao, Yang Geng. Close-loop Control for Selective Harmonic Compensation Active Power Fil ter. Journal of Tsinghua Univ (Sci & Tech), vol. 44(2004), pp.130-133.

[5] Guo Xizheng, Han Qiang, Yang Geng, Yang Gongxun. Closed-Loop Control Method and Implementation of Selective Harmonic Type Active Power Filters. Transactions of China Electrotechnical Society, vol. 21(2006), pp.51-55.
