Land Subsidence Detection by PSInSAR^TM Based on TerraSAR-X Images

Abstract:

Land subsidence in urban area is becoming a severe geological hazard disturbing the urban construction and development. Persistent Scatterer Interferometric Synthetic Aperture Radar (PSInSAR) technique has demonstrated a good capability of monitoring the large scale land deformation. High resolution and short wave radar data can help to improve the precision of deformation detection based on PSInSAR. In this paper, 15 scenes of TerraSAR-X SAR data are used to derive the estimation of the subsidence rate in the Wuqing district, Tianjin city in China. The combination of TIN and nearest-connection method (NCM) are first used to establish the differential network model. The results show that high resolution TX image can dramatically increase the valid PSs and improve investigation reliability, especially in linear man-made constructs.

• Periodical: Advanced Materials Research (Volumes 301-303)
• Pages: 641-645
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.301-303.641
• Online since: July 2011
• Authors: Hong Liang Jia, Bing Yu, Rui Zhang, Ming Zhi Sang
• Keywords: Linear Construct, Linear Deformation, PSInSAR, TerraSAR-X

References

[1] Y. X Tang, H. Zhang, C. Wang, Measurement of land subsidence based permanent scatterer radar interferometry in Suzhou, Progress in Natural Science. Vol. 16, no. 8, pp.1015-1020, 2006 (in Chinese).

[2] A. Ferretti, C. Prati, and F. Rocca, Nonlinear subsidence rate estimation using permanent scatterers in differential SAR interferometry, IEEE Trans. Geosci. Remote Sens. vol. 38, no. 5, p.2202–2212, (2000).

DOI: 10.1109/36.868878

[3] A. Ferretti, C. Prati, and F. Rocca, Permanent scatterers in SAR interferometry, IEEE Trans. Geosci. Remote Sens., vol. 39, no. 1, p.8–20, (2001).

DOI: 10.1109/36.898661

[4] Guoxiang Liu, Hongguo Jia, Rui Zhang, Minyi Cen, Tonggang Zhang. Subsidence Detection by PSInSAR Based on High Resolution TerraSAR-X Images". Progress In Electromagnetics Research Symposium Proceedings, Xi, an, China, March 22-26, (2010).

[5] Bovenga, Fabio; Nitti, Davide Oscar; Refice, Alberto; Nutricato, Raffaele; Chiaradia, Maria Teresa, Multi-temporal DInSAR analysis with X-band high resolution SAR data: examples and potential, Proceedings of SPIE - The International Society for Optical Engineering, v 7829, 2010, SAR Image Analysis, Modeling, and Techniques.

DOI: 10.1117/12.866459

[6] Markus Even, Alexander Schunert, Karsten Schulz, and Uwe Soergel Proc. SPIE 7477, 74771K (2009); Online Publication Date: Sep 29, (2009).

[7] Liu G X, Sean M. Buckley, Ding X L, et al. Estimating Spatiotemporal Ground Deformation With Improved Persistent-Scatterer Radar Interferometry,. IEEE Trans Geosci Remote Sens, 2009, 47(9): 3209-3214.

DOI: 10.1109/tgrs.2009.2028797
