Multi-Feature Extraction for Drivable Road Region Detection with a Two-Dimensional Laser Range Finder

Abstract:

A multi-feature extraction method using a single 2D Laser Range Finder is proposed to provide the information of drivable road region for the Unmanned Ground Vehicle in structured environment. The whole process consists of two main steps: first, the curbs are extracted from the range data using the wavelet transform method, and evaluated by a road scanning model; then, the drivable region is detected based on the average height and flatness. A mathematical model for curb and road detection based on grid map is built to guide the vehicle. The algorithm distinguishes itself from the most existing methods which detect curbs only, it takes advantage of the flatness of surface between extracted curbs is employed as another feature for drivable road region detection. Furthermore, laser intensity data from the same laser range finder is introduced to supply a new restriction for surface evaluation. Experimental results verify the feasibility and stability of the method.

• Periodical: Advanced Materials Research (Volume 304)
• Pages: 381-386
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.304.381
• Online since: July 2011
• Authors: Yu Wen Hu, Xin Li, Jian Wei Gong
• Keywords: Data Analysis, Intelligent Vehicle, Laser Range Finder, Road Region Detection

References

[1] A. A. M. Assidiq, O. O. Khalifa, R. Islam, and S. Khan, in: Real time lane detection for autonomous vehicles, 2008 International Conference on Computer and Communication Engineering. pp.82-88(2008).

DOI: 10.1109/iccce.2008.4580573

[2] O. O. Khalifa, A. A. M. Assidiq, and A. H. A. Hashim, in: Vision-Based Lane Detection for Autonomous Artificial Intelligent Vehicles, in IEEE International Conference on Semantic Computing, pp.636-641(2009).

DOI: 10.1109/icsc.2009.113

[3] Z. Shengyan, J. Yanhua, X. Junqiang, G. Jianwei, X. Guangming, and C. Huiyan, in: A novel lane detection based on geometrical model and Gabor filter, Intelligent Vehicles Symposium (IV), 2010 IEEE, pp.59-64(2010).

DOI: 10.1109/ivs.2010.5548087

[4] S. Youjin, J. Changbae, and C. Woojin, in: Drivable road region detection using a single laser range finder for outdoor patrol robots, 2010 IEEE Intelligent Vehicles Symposium (IV), pp.877-882( 2010).

DOI: 10.1109/ivs.2010.5548080

[5] Y. Chunhe and Z. Danping, in: Road Curbs Detection Based on Laser Radar, 2006 8th International Conference on Signal Processing(2006).

DOI: 10.1109/icosp.2006.346072

[6] W. S. Wijesoma, Kodagoda, K. R. S., Balasuriya, A. P., in: Road-boundary detection and tracking using ladar sensing, vol. 20 of IEEE Transactions on Robotics and Automation, pp.456-464(2004).

DOI: 10.1109/tra.2004.825269

[7] K. R. S. Kodagoda, W. S. Wijesoma, and A. P. Balasuriya, in: Road feature extraction using a 2D LMS, vol. 1 of 2002 7th International Conference on Control, Automation, Robotics and Vision, pp.453-458(2002).

DOI: 10.1109/icarcv.2002.1234864

[8] K. R. S. Kodagoda, W. S. Wijesoma, and A. P. Balasuriya, in: Road curb and intersection detection using a 2D LMS, vol. 1 of 2002 IEEE/RSJ International Conference on Intelligent Robots and Systems, pp.19-24(2002).

DOI: 10.1109/irds.2002.1041355

[9] J. Siegemund, D. Pfeiffer, U. Franke, Fo, x, and W. rstner, in: Curb reconstruction using Conditional Random Fields, 2010 IEEE Intelligent Vehicles Symposium (IV), pp.203-210( 2010).

DOI: 10.1109/ivs.2010.5548096

[10] G. Liang, Z. Yongsheng, L. Zhengguo, and B. Quanfu, in: Automated road extraction from LiDAR data based on intensity and aerial photo, 2010 3rd International Congress on Image and Signal Processing (CISP), pp.2130-2133(2010).

DOI: 10.1109/cisp.2010.5647354

[11] B. Jaemin, K. Sung Hoon, R. Myung Chan, and S. Junyoung, in: Autonomous navigation of transport robot in the urban environment, 2010 15th International Conference on Methods and Models in Automation and Robotics (MMAR), pp.76-81(2010).

DOI: 10.1109/mmar.2010.5587262

[12] C. Urmson, et al., in: Autonomous driving in urban environments: Boss and the Urban Challenge, vol. 25 of Journal of Field Robotics, pp.425-466(2008).
