Design Analysis of a New Transmission Device for High-Speed Precision Micro-Shafting

Abstract:

This paper presented a new transmission device for high-speed precision micro-shafting, which consists of an elastic shaft coupling and a collet, both which are integrated with the drive shaft, and a clamp ring, and meanwhile accomplished the detailed structure parameters design calculation by theoretical analysis and simulated computation with an application to an ultra-high speed micro-spindle, which shows the transmission device rational and feasible.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1714-1719
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1714
• Online since: August 2011
• Authors: Wei Li, Zhi Xiong Zhou, Tie Jun Song, Hang Xiao
• Keywords: Calculation Model, Micro-Shafting, Micro-Spindle, Transmission Device

References

[1] X. K. Chen: Theory research of Schmidt Offset Coupling, Xi'an University of Technology, Xi'an, (2007)

[2] H. P. Luo: Research on key technologies of micromachine for electrochemical micromachining (ECMM) with nanosecond pulse voltage, Hunan University, Changsha, (2009)

[3] H. W. Liu: Mechanics of materials, High Education Press, Beijing, (1991)

[4] J. P. Pathak: Design, assembly, and testing of an ultra-high-speed micro-milling spindle, University of Florida, Gainesville, (2003)

[5] W. C. Shin, S. K. Ro, H. W. Park, and J. K. Park: International Journal of Machine Tools and Manufacture. 49 (2009) 579-585
