The Research of the Four-Bar Bionic Active Knee

Abstract:

The robot joints are usually rotational axis by two link joints, bionic features is not strong. The shortcomings of intelligent MR damper control multi-axis bionic knee can only provide resistance and certain sizes to regain momentum, cannot provide larger power, therefore this paper gives by the multi-axis four-bar structure, ball screw transmission multiaxial bionic active knee institutions. And analysis the human leg institutions and commonly used two-bar structure, through multi-variable optimization method to solve the design parameters of knee joint structure, the motor angular velocity and torque. And established in a bionic active the knee's virtual prototype.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1988-1991
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1988
• Online since: August 2011
• Authors: Ki Jun Kim, Cheng Dong Wu, Fei Wang, Shi Guang Wen
• Keywords: Active Intelligent Knee, Four-Bar Bionic Knee, Multi-Variable Optimization
