Trajectory Performances Test for Arc Welding Robot Based on the Non-Contact Laser Tracing Measurement Technology

Abstract:

The aim of this paper is to test the trajectory precision of the execution terminal of the industrial robot based on a non-contact laser tracing measurement technique. The target is found in terms of tracing mirror attached in measurement position. This method utilizes the linear motion units and photo detection units to trace the target actively. The measurement of the target coordinates are measured with the laser interferometer linear measurement module and the grating ruler. This system can achieve the trajectory measurement of the planar motion objects without contact in real-time condition and also possesses the high precision. The experimental work and calculation were performed in order to achieve the trajectory precision of the research.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1997-2002
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1997
• Online since: August 2011
• Authors: Xiao Jin Zhang, Jia Li, Si Jun Zhu, Yu Zhang
• Keywords: Industrial Robot, Non-Contact Laser Tracing Measurement Technique, Trajectory Precision

References

[1] Wang Jia, Lu Gang. Aviation Metrology & Measurement Technology，1997,17(3)：34-39.

[2] Wang Jia, Lu Gang. Aviation Metrology & Measurement Technology，1997,17(4)：34-38.

[3] Yu Jia, Liu Yongdong. Acta Metrologica Sinica，2000，21 (1)：34～39.

[4] Li Yongqian, Zhu Quanming. Aeronautical Manufacturing Technology，1999，(3)：13～l5.

[5] FARO. Aeronautical Manufacturing Gechnology, 2009,(09).

[6] Li Xinghua. Tianjing University:Tianjing,2003.

[7] AFNOR. Norme ISO9283, AFNOR, 1998.
