Milling Force Predicting Modeling and Analysis for Helical Tooth End Mill on Inside Corner

Abstract:

Milling force is an important parameter during machining, which is directly related to the tool deformation, the tool life, the quality of the part surface, cutting heat, etc. In actual production, the cutting force on inside corner is more complex than the linear. For lack of the accurate cutting force information, there is liable to cause over-cut and owes-cut, rough surface, cutter breaking phenomenon. According to the structural characteristics of the corner, the cutting force model is established, which cutting force is further subdivided and the overall prediction accuracy is improved. Effects of different helix angle and forward amount each gear on cutting force. A good agreement is shown between the model simulation and the results of the experimental ones. The research provides a theoretical basis of predicting the cutting force on inside corner, and it is also helpful for further and practice.

• Periodical: Advanced Materials Research (Volumes 311-313)
• Pages: 1290-1293
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.311-313.1290
• Online since: August 2011
• Authors: Yu Hua Ji, Tong Xiao, Jian Qiang Zhou
• Keywords: Cutting Force, Cutting Force Model, End Mill, Inside Corner

References

[1] S Engin, Y Altintas. Mechanics and dynamics of general milling cutters (Part I): helical end mills [J]. International Journal of Machine Tools & Manufacture, 41 (2001):2195-2212.

DOI: 10.1016/s0890-6955(01)00045-1

[2] Xiwen Li, Runsheng Du. Characteristics of Time Domain of Cutting Force Model in the Milling [J]. Journal of huazhong university of science and technology, 2000, 28(7):41-43. In Chinese.

[3] Qidong Wang, Zhanqiang Liu, Aimin Tang, Tao Zeng. Milling Force Predicting Modelling and Numerical Simulation for Helical Tooth Cylindrical Milling Cutters (Part Ⅰ{TTP}8544 :Influence of Cutter Geometry Parameters on Milling Force) [J]. Tool Engineering, 2011,45(3):17-22. In Chinese.

[4] Zhenyu Shi, Zhanqiang Liu, Pifen Zhao. Study on Modeling and Experiment of Cutting Forces for High Speed Milling of AISI440C Stainless Steel[J].Tool Engineering,2010,44(3):8-10. In Chinese.

[5] Aijun Tang, Zhanqiang Liu. Three-dimensional Stability and Deformation of Thin-walled Part in High Speed End Milling[D]. Shandong university mechanical college, 2009:39-47. In Chinese.

DOI: 10.1109/ical.2008.4636208

[6] S Leung Soo, Richard C Dewes, David K. Aspinwall.3D FE modeling of high-speed ball nose Endmilling[J].InternationalJournalAdvancedManufacturingTechnology.

DOI: 10.1007/s00170-010-2581-y

[7] Haibin Li, Ning He, Liang Li. Modeling of Milling Force and Experiment Analysis for End Milling with Variable Pitch[J]. Tool Engineering, 2010,44 (12).10-13. In Chinese.

[8] Lei Yang, Yaoyao Shi, Qiaofeng Yang, ChuangGuo Hu. Cutting Force Prediction for Milling Titanium TC11[J]. Manufacturing skill and tools, 2007(1):35-37. In Chinese.
