Determination of the Optimum Fitting Probabilistic Distribution for Fracture Toughness in Small Sample Size

Abstract:

Plane strain fracture toughness is an important mechanical performance index for damage tolerance design, so how to obtain this value through test deserves consideration. In this paper, the ductile fracture toughness test was performed. It was difficult for the specimen with big dimensions in the case of plane strain to be carried out through ordinary testing machine with lower capacity because of the higher fracture toughness value of the material, that it was attained indirectly for plane strain fracture toughness value by the way of ductile fracture toughness test and pertinent formula calculation if proper specimen selected. The fracture property tests according to the corresponding standard were conducted. The compact tension specimens were obtained from the main rotor butt of a helicopter in service. Based on the single specimen measuring ductile fracture toughness method, the experiments of measuring the ductile fracture toughness were carried out. A method was given to determine the optimum fitting probabilistic distribution function of fracture toughness in the small sample size. The statistic results show that the optimum probabilistic distribution function of ductile fracture toughness is the Extreme Maximum. Value distribution. The following factors were taken into account, the linear relative coefficient, total fit effect probability relative coefficient, consistency with the relevant fatigue physics and tail most importantly, safety of design evaluation. The shape parameter, scale parameter, and location parameter are -1.1231, 860.53, 6036.4, respectively. The statistical variation coefficient is 11.22%. The result shows that there is a large risk probability for a definite value to fracture toughness only with one or two pieces of samples according to the test.

• Periodical: Advanced Materials Research (Volume 320)
• Pages: 263-268
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.320.263
• Online since: August 2011
• Authors: Wen Lin Liu, Ri Jie Yang, Zhi Tao Mu, Xiu Xia Wang, Da Zhao Yu
• Keywords: Ductile Fracture Toughness Test, Fracture Toughness, Probabilistic Distribution, Small Sample Size

References

[1] XIONG Jun-jiang, PENG Jun-hua, GAO Zhen-tong. Reliability Methods to Determine Fracture Toughness KIC and Fracture Threshold Value ΔKth. Journal of Beijing University of Aeronautics and Astronautics, Vol 25, No. 6(2000), p.694~696 (In chinese).

[2] Bahram Farahmand and Frank Abdi. Probabilistic fracture toughness, fatigue crack growth estimation resulting from material uncertainties. Symposium on Probabilistic aspects of Life predictions Sponsored by ASTM Committee E08 on Fatigue and Fracture. November 6-7, 2002, Fontain Hilton Resort Miami Beach, Florida, USA.

DOI: 10.1520/stp11279s

[3] Jianghong Gong, Yufeng Chen, Chunyan Li. Statistical analysis of fracture toughness of soda-lime glass determined by indentation[J]. Journal of Non-Crystalline Solids 279 (2001) 219-223.

DOI: 10.1016/s0022-3093(00)00418-x

[4] ZHAO Yong-xiang, HE Chao-ming, YANG Bing. Reasonable statistical model for random fracture toughness data of lz50 axle steel. Engineering Mechanics, Vol. 22 No. 4(2005), p.149~154 (In chinese).

[5] ZHAO Yong-xiang, SUN Ya-fang, GAO Qing. Unified linear regression method for the analysis of seven commonly used statistical distributions. Journal of Mechanical Strength, Vol. 23 No. 1(2001), p.102~106 (In chinese).

[6] ZHAO Yong-xiang, SUN Ya-fang, GAO Qing. Unified Approach for Determining an Appropriate Assumed Distribution of Limited Fatigue Reliability Data. China Mechanical Engineering, Vol. 12 No. 12 (2001), p.1343~1349 (In chinese).

[7] LIU Min, CHEN Shi-xuan. The Determination for the Fracture Toughness Probabilistic Distribution of Austenitic Stainless Steel Weld Metal. Materials for Mechanical Engineering, Vol. 24 No. 4 (2000), p.1~4 (In chinese).

[8] ZHANG Ya-jun, WANG Jia-min, ZHANG Xin-yao etc. Test Study of Fracture Toughness on Super high Strength Structural Steel AF1410. Materials Exploitation and Application, Vol. 10 (2008), p.12~15 (In chinese).
