Automatic Measurement of Concrete Deformation Field under Uniaxial Compression Based on DSCM

Abstract:

As a kind of optical approach to measure full field deformation with the properties of non-contact, Digital Speckle Correlation Method (DSCM) has been adopted widely with the development of computer technology. The deformation of concrete under external loads is usually uneven and thus it should be characterized by full filed measurement so as to obtain accurate results. It should be effective for engineering to monitor the deformation of concrete by using digital speckle correlation method, and such monitoring is helpful to study the law of uneven deformation of concrete and discover its damage characteristics. The images of the surface of concrete specimens at the different stress were captured and recorded with a high-resolution CCD camera during uniaxial compression process. An own software was developed to analyze these images by DSCM. The nature texture of the specimen surface were searched and matched in different images, therefore the displacement field and the strain field of the surface of concrete specimens were calculated out. Experimental studies have shown that digital speckle correlation method can be well used to calculate the accurate deformation of concrete just through a direct photograph of concrete surface under different loads.

• Periodical: Advanced Materials Research (Volume 320)
• Pages: 58-63
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.320.58
• Online since: August 2011
• Authors: Wei Weng, Rui Dong Peng, Hong Bin Liu, Wei Jia Ma, Sheng Hua Zhang
• Keywords: Concrete, Deformation, Digital Speckle Correlation Method, Uniaxial Compression

References

[1] Yamaguchi I: A laser-speckle strain gauge. Journal of Physics E: Scientific Instruments, Vol. 14, No. 11, (1981), p.1270~1273.

DOI: 10.1088/0022-3735/14/11/012

[2] W.H. Peters and W.F. Ranson: Digital imaging technique in experimental stress analysis. Opt. Eng, Vol. 21, No. 3(1982), p.427~431.

[3] Pan Yishan, Yang Xiaobin, Ma Shaopeng: Study on deformation localization of rock by white light digital speckle correlation method. Journal of Experimental Mechanics, Vol. 16, No. 2(2001): 220-225.

[4] Pan Yishan, Yang Xiaobin, MA Shaopeng, et al: Experimental study on the deformation localization of rock-soil material. Journal of China Coal Society, Vol. 27, No. 3(2002): pp.281-284.

[5] MA Shaopeng: Development and application of digital speckle correlation method of failure measurement for rock mateials[Ph.D. Thesis]. Beijing: Tsinghua University, (2003).

[6] MA SP, XU XH, ZHAO YH, et al.: Geo-DSCM system and its application to deformation measurement of rock mechanics. International Journal of Rock Mechanics and Mining Sciences, Vol. 41, No. 3(2004)：p.411–412.

DOI: 10.1016/j.ijrmms.2003.12.007

[7] Ma Shaopeng, Zhou Hui: Surface strain field evolution of rock specimen during failure process[J]. Chinese Journal of Rock Mechanics and Engineering, Vol. 27, No. 8(2008): pp.1667-1673.

[8] Guo Li-Ping, Sun Wei, He Xiao-Yuan, et al.: Application of DSCM in prediction of potential fatigue crack path on concrete surface. Engineering Fracture Mechanics, Vol. 75(2008): p.643–651.

DOI: 10.1016/j.engfracmech.2007.01.023

[9] Guo Li-Ping, Andrea Carpinteri, Andrea Spagnoli, et al. Experimental and numerical investigations on fatigue damage propagation and life prediction of high-performance concrete containing reactive mineral admixtures. International Journal of Fatigue, Vol. 32(2010).

DOI: 10.1016/j.ijfatigue.2009.05.009

[10] Cao Yanyan, Ma Shaopeng, Wang Xian, et al. A new definition of damage variable for rock material based on the spatial characteristic of deformation fields[J]. Advanced Material Research, v146-147(2011), pp.865-868.

DOI: 10.4028/www.scientific.net/amr.146-147.865

[11] ShengWang Hao, Ju Sun: Observation on Pattern Competition and Selection of Strain Localization in rocks under uniaxial compression. Advanced Material Research, v 41-42(2008): pp.283-289.

DOI: 10.4028/www.scientific.net/amr.41-42.283

[12] Jin Guanchang: Computer Aided Optical Measurement[M]. Beijing：Tsinghua University Press(1997). p.143–174.

[13] S. Choi and S.P. Shah: Measurement of deformations on concrete subjected to compression using image correlation. Experimental mechanics, Vol. 37, No. 2, (1997), p.307~313.

DOI: 10.1007/bf02317423

[14] Peng Zhou and Kenneth E. Goodson: Subpixel displacement and deformation gradient measurement using digital. image/speckle correlation (DISC). Opt. Eng, Vol. 40, No. 8(2001), p.1613~1620.

DOI: 10.1117/1.1387992

[15] Jiabai Rui, Guanchang Jin and Bingye Xu: A new digital speckle correlation method and its application. ActaMechanics, Vol. 26, No. 5, (1994), p.599~607.
