Fabrication and Application of CVD Diamond-Coated Copper Wire Drawing Die

Abstract:

To improve the surface quality and adhesion of diamond film is the key factors to realize CVD diamond coating widely applied in the wear-resistance parts field. Through optimizing deposition process parameters, the article used the straight wiredrawing chemical vapor deposition to depose the diamond film in the bore surface of WC-CO carbide wiredrawing mould. The surface topography of the coating, film quality and surface roughness were detected and the preparation of CVD diamond film coated wire drawing mould in drawing copper wires production line was applied. The experimental results show that working life of diamond film coated wire drawing mould improved to 40~ 50 of that traditional hard alloy mould, and the controlled copper wire had the better precision and surface quality.

• Periodical: Advanced Materials Research (Volumes 328-330)
• Pages: 1182-1187
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.328-330.1182
• Online since: September 2011
• Authors: Qing Shun Tang, Yuan Hui Yang
• Keywords: Diamond Coating, Drawing Processing, Hot Filament Chemical Vapor Deposition (HFCVD), Wiredrawing Die

References

[1] R.W. YU and T.Q. Xie: Drawing die and the lubricant (Light Industry Press, 1991), (In Chinese).

[2] L.C. Nistor, J. Van Landuyt and V.G. Ralchenko: Diamond and Related Materials, (1997) No. 6, p.159.

[3] H.W. Xin and Z.M. Zhang: Diamond and Related Materials, (2002) No. 11, p.228.

[4] D. M. Gruen: Annu Rev. Mater . Sci, (1999) No. 29, p.211.

[5] D.H. Dai and K.S. Zhou: Diamond film deposition technology and application (Metallurgical Industry Press, 2001), (In Chinese).

[6] G.H. Chen and Y. Zhang: Preparation and application of diamond films (Chemical Industry Press, 2004), (In Chinese).

[7] O. Ayanori and M. Junichi: J.P. Patent 01, 062, 213. (1989).

[8] M. Murakawa, S. Takeuchi and K. Yoshida: The 2th International Conference on Application of Diamond Films and Related Materials, (1993), p.589.

[9] D. Ivan and B.G. Elizaboeth: F.R. Patent 2, 850, 116. (2004).

[10] F. H. Sun, X. G. Wang, Z.M. Zhang, H.S. Shen and M. Chen: Key Engineering Materials, Vols. 259-260 (2004), p.68.

[11] L. Gou, X.M. An and J.G. Ran: Tool technology, Vol. 41 (2007) No. 6, p.62, (In Chinese).

[12] Z.M. Zhang, H.S. Shen and F.H. Sun: Tool technology, Vol. 34 (2000) No. 4, p.13, (In Chinese).

[13] Z.M. Zhang, H.S. Shen and F.H. Sun: Diamond and Related Materials, (2001) No. 10, p.33.

[14] Z.M. Zhang, H.S. Shen and F.H. Sun: Wire & Cable (2003) No. 4, p.9, (In Chinese).

[15] S.G. Guo, Z.M. Zhang and H.H. Shen: Light and cable and Their Applications, (2007) No. 1, p.9.
